产品技术规格
| 1 | 0.493 |
|---|---|
| 20 | 0.47 |
| 3500 | 0.258 |
| A126742CT-ND | Cut Tape (CT) |
| A126742TR-ND | Tape & Reel (TR) |
| Assembly Country of Origin | Not available |
| batch | ZK |
| BRHTS | 85389090 |
| CAHTS | 8536900020 |
| CNHTS | 8538900000 |
| Compatible Insulation Diameter Range | 2.2 – 3 mm [ .087 – .118 in ] |
| Compatible With Agency/Standards Products | LV214 |
| Compatible With Wire Base Material | Copper |
| Compatible With Wire & Cable Type | Discrete Wire |
| Conforms to Automation Guideline | Yes, DIN 72036 Automation of Wiring Harness Production, Version June 2024 | Yes, KOMAX Guideline for automatic component insertion for electrical connections, Version 5.0 (March 2018) |
| Contact Fabrication | Stamped & Formed |
| Contact Finish | Tin |
| Contact Finish Thickness | - |
| Country of Diffusion | Not available |
| Country of Origin | Czech Republic |
| Crimp Type | F-Crimp |
| DigiKey编号 | A126742TR-ND |
| ECCN | EAR99 |
| ENG_CVM_1241390-1_C6.2d_dxf.zip | https://www.te.com/commerce/DocumentDelivery/DDEController?Action=srchrtrv&DocNm=1241390-1&DocType=Customer%20View%20Model&DocLang=English&DocFormat=2d_dxf.zip&PartCntxt=1241390-1 |
| ENG_CVM_1241390-1_C6.3d_igs.zip | https://www.te.com/commerce/DocumentDelivery/DDEController?Action=srchrtrv&DocNm=1241390-1&DocType=Customer%20View%20Model&DocLang=English&DocFormat=3d_igs.zip&PartCntxt=1241390-1 |
| ENG_CVM_1241390-1_C6.3d_stp.zip | https://www.te.com/commerce/DocumentDelivery/DDEController?Action=srchrtrv&DocNm=1241390-1&DocType=Customer%20View%20Model&DocLang=English&DocFormat=3d_stp.zip&PartCntxt=1241390-1 |
| ENG_CVM_1241390-1_C6.pdf | https://www.te.com/commerce/DocumentDelivery/DDEController?Action=srchrtrv&DocNm=1241390-1&DocType=Customer%20View%20Model&DocLang=English&DocFormat=pdf&PartCntxt=1241390-1 |
| GER_SS_108-18717_B.pdf | https://www.te.com/commerce/DocumentDelivery/DDEController?Action=srchrtrv&DocNm=108-18717&DocType=Specification%20Or%20Standard&DocLang=German&DocFormat=pdf&PartCntxt=1241390-1 |
| GER_SS_114-18022_N.pdf | https://www.te.com/commerce/DocumentDelivery/DDEController?Action=srchrtrv&DocNm=114-18022&DocType=Specification%20Or%20Standard&DocLang=German&DocFormat=pdf&PartCntxt=1241390-1 |
| GER_SS_114-18387_G.pdf | https://www.te.com/commerce/DocumentDelivery/DDEController?Action=srchrtrv&DocNm=114-18387&DocType=Specification%20Or%20Standard&DocLang=German&DocFormat=pdf&PartCntxt=1241390-1 |
| HTSUS编码 | 8536.90.4000 |
| Insulation Option | Uninsulated |
| Interface Plating | Tin (Sn) |
| JPHTS | 853690000 |
| Mating Tab Thickness (in) | .024 | .031 |
| Mating Tab Thickness (mm) | .6 | .8 |
| Mating Tab Width | 2.8 mm [ .11 in ] |
| MXHTS | 8536902800 |
| 工作温度（Max） | 130 °C [ 266 °F ] |
| 工作温度 | -40 – 130 °C [ -40 – 266 °F ] |
| Packaging Method | Reel |
| Packaging Quantity | 3500 |
| PART-NO. CROSS-REFERENCE INFO | https://www.te.com/commerce/DocumentDelivery/DDEController?Action=srchrtrv&DocNm=1241390&DocType=Customer%20Drawing&DocLang=English&DocFormat=tif&PartCntxt=1241390-1 |
| Pin or Socket | Socket |
| Primary Locking Feature | Locking Lance |
| Product Features & Characteristics | Select All |
| Product Terminates To | Wire |
| REACH状态 | REACH not applicable |
| Receptacle Style | 180° |
| RoHS状态 | RoHS Compliant |
| Sealable | No |
| Standard Pack Qty | 3500 |
| TARIC | 8536901000 |
| Terminal Seal Type | Unsealed |
| Terminal Transmits | 0 – 24 A (Low Power) |
| Terminal Type | Receptacle |
| Termination Method to Wire & Cable | Crimp |
| TE内部描述 | AMP MCP 2.8K, CONTACT |
| TE内部编号 | 1241390-1 |
| Type | Stamped |
| Typical Current Rating (A) | 22 |
| USHTS | 8536904000 |
| Wire Contact Termination Area Plating Material | Tin |
| Wire Gauge | 13-17 AWG |
| Wire Size (mm²) | 1.5 – 2.5 |
| Wire Size Search (mm²) | 1.5 | 2 | 2.5 |
| 与电线基础材料兼容 | 铜 |
| 主要锁定特性 | 锁定枪 |
| 交期 | 171 Days |
| 产品名称 | 1241390-1 (TE Connectivity) |
| 产品描述 | Automotive Terminals, Receptacle, Mating Tab Width 2.8 mm [.11 in], Tab Thickness .6 mm [.024 in / .031 in], AMP MCP Connector System |
| 产品状态 | Id：0；Status：Active |
| 产品端接到 | 导线 |
| 产地 | 中国/CHN |
| 公端/母端 | 母端 |
| 制造商交期（周） | 34 |
| 包装方式 | 卷 |
| 单位重量（kg） | 0.000519 |
| 压接类型 | F 型压接 |
| 参考单价（USD） | 0.18 |
| 可密封性 | 否 |
| 可用库存 | 28367 |
| 品名 | 盘装端子 |
| 品牌归属地 | 国际 |
| 基本分类 | 连接器 |
| 子品牌 | AMP |
| 官方产品图片1 | https://www.te.com/content/dam/te-com/catalog/part/012/413/902/1241390-2-t1.jpg/jcr:content/renditions/product-details.png |
| 对接公端厚度 | .024 in |
| 对接公端宽度 | .11 in |
| 导线端子端接区域电镀材料 | 锡 |
| 封装数量 | 3500 |
| 工作温度范围 | 176 °F、-40 – 266 °F |
| 年份批次 | 202606 |
| 插座种类 | 180° |
| 数据手册 | https://www.te.com/commerce/DocumentDelivery/DDEController?Action=srchrtrv&DocNm=1241390&DocType=Customer%20Drawing&DocLang=English&PartCntxt=1241390-1&DocFormat=pdf |
| 替代型号 | 922-280-1012（JiDC(济德)） |
| 湿敏等级 | 1 (Unlimited) |
| 端子传导 | 0 – 24 A（低功率） |
| 端子制造 | 冲压成形 |
| 端子大小 | 2.8K |
| 端接方法 | 压接 |
| 线径 | 1 – 2.5 mm² |
| 线规-AWG | 13 AWG |
| 绝缘选项 | 非绝缘 |
| 触头镀层 | 锡 |
| 贸泽编号 | 571-1241390-1 |
| 适用的绝缘层直径范围 | .087 – .118 in |
| 零件编号 | 1241390-1 |
| 额定电流 | 22A |
| 包装 | Reel |
| 间距 | 2.8K |
| 系列 | MCP 2.8 |
| 端接方式 | Crimp |
相关产品信息
同品牌、系列或类别的相似产品（不代表兼容或可替代）
已核验询价信息
- 包装方式
- 卷
- Packaging
- Reel
- 最小订购量
- 3500
产品资料
1241390-1
1241390-1 是 TE Connectivity AMP Connectors 的 Automotive Terminals产品。本页汇总官方技术资料、贸易合规、包装和国内供货信息。
品牌
TE Connectivity AMP Connectors
制造商
TE Connectivity AMP Connectors
产品类别
Automotive Terminals
技术参数
| 公端/母端 | 母端 |
|---|---|
| 包装方式 | 卷 |
| 品牌归属地 | 国际 |
| 端接方法 | 压接 |
| 系列 | AMP MCP Connector System |
| 线规-AWG | 13 AWG |
| 触头镀层 | 锡 |
| 额定电流 | 22A |
| TE内部编号 | 1241390-1 |
| 与电线基础材料兼容 | 铜 |
| 主要锁定特性 | 锁定枪 |
| 产品端接到 | 导线 |
| 分类 | 汽车端子 |
| 压接类型 | F 型压接 |
| 可密封性 | 否 |
| 子品牌 | AMP |
| 对接公端厚度 | .024 in |
| 对接公端宽度 | .11 in |
| 导线端子端接区域电镀材料 | 锡 |
| 封装数量 | 3500 |
| 工作温度范围 | 176 °F、-40 – 266 °F |
| 描述 | AMP MCP 2.8K, CONTACT |
| 插座种类 | 180° |
| 端子传导 | 0 – 24 A（低功率） |
| 端子制造 | 冲压成形 |
| 端子大小 | 2.8K |
| 线径 | 1 – 2.5 mm² |
| 绝缘选项 | 非绝缘 |
| 适用的绝缘层直径范围 | .087 – .118 in |
| 零件编号 | 1241390-1 |
| Packaging | Reel |
| Standard Pack Qty | 3500 |
| Type | Stamped |
| Pin or Socket | Socket |
| Contact Termination | Crimp |
| Wire Gauge | 13-17 AWG |
| Contact Finish | Tin |
| Contact Finish Thickness | - |
| 单位重量（kg） | 0.000519 |
| Terminal Type | Receptacle |
采购与包装
| 最小订购量 | 3500 |
|---|---|
| 订购倍数 | 3500 |
合规信息
| RoHS状态 | RoHS Compliant |
|---|---|
| REACH状态 | REACH not applicable |
| 湿敏等级 | 1 (Unlimited) |
| ECCN | EAR99 |
| HTSUS编码 | 8536.90.4000 |
| CNHTS | 8538900000 |
| TARIC | 8536901000 |
| CAHTS | 8536900020 |
| USHTS | 8536904000 |
| JPHTS | 853690000 |
| MXHTS | 8536902800 |
| BRHTS | 85389090 |
| Country of Origin | Czech Republic |
| Assembly Country of Origin | Not available |
| Country of Diffusion | Not available |
其他信息
| 产地 | 中国/CHN批量参考批次：202606 |
|---|---|
| 品名 | 盘装端子 |
参数来自已配置的数据源，仅供选型参考；订购前请以制造商最新资料为准。
