TE Connectivity 776273-2 连接器胶壳

Name: 776273-2 (TE Connectivity)
Brand: TE Connectivity
SKU: 776273-2

价格请询价

添加到心愿单

销售与网站使用条款
价格、库存与交期以订单确认为准

联系我们

香港标准配送：17:00 截单，处理 3 个工作日 + 运输 3 个工作日，周一至周五，免运费。查看配送政策

产品技术规格

1	25.463
20	24.25
2992-776273-2-ND	Bulk
3D_CVM_CVM_776273-2_E.pdf	https://www.te.com/commerce/DocumentDelivery/DDEController?Action=srchrtrv&DocNm=CVM_776273-2&DocType=Customer%20View%20Model&DocLang=3D&DocFormat=pdf&PartCntxt=776273-2
A139346-ND	Bulk
Assembly Country of Origin	Not available
batch	N
BRHTS	85389090
Cable Exit Angle (°)	180
CAHTS	8538903900
Centerline (Pitch)	4 mm [ .157 in ]
Circuit Application	Power
CNHTS	8538900000
Color	Natural
Connector & Contact Terminates To	Wire & Cable
Connector Height	34.6 mm [ 1.362 in ]
Connector & Keying Code	2
Connector Mounting Type	Free-Hanging (In-Line)
Connector Position Assurance Capable	Yes
Connector Shape	Rectangular
Connector System	Wire-to-Board
Connector Type	Plug
Contact Current Rating (Max) (A)	17
Country of Diffusion	Not available
Country of Origin	Mexico
Customer Drawing	https://www.te.com/commerce/DocumentDelivery/DDEController?Action=srchrtrv&DocNm=2293782&DocType=Customer%20Drawing&DocLang=English&DocFormat=pdf&PartCntxt=776273-2
DigiKey编号	2992-776273-2-ND
ECCN	EAR99
ENG_AAD_CSA_CERT_164196_1062842_623301_C1_E.pdf	https://www.te.com/commerce/DocumentDelivery/DDEController?Action=srchrtrv&DocNm=CSA_CERT_164196_1062842_623301_C1&DocType=Agency%20Approval%20Document&DocLang=English&DocFormat=pdf&PartCntxt=776273-2
ENG_AAD_CSA_CERT_164196_1062842_623301_Rating_E.pdf	https://www.te.com/commerce/DocumentDelivery/DDEController?Action=srchrtrv&DocNm=CSA_CERT_164196_1062842_623301_Rating&DocType=Agency%20Approval%20Document&DocLang=English&DocFormat=pdf&PartCntxt=776273-2
ENG_AAD_UL_CERT_E28476_19920617_C1_G.pdf	https://www.te.com/commerce/DocumentDelivery/DDEController?Action=srchrtrv&DocNm=UL_CERT_E28476_19920617_C1&DocType=Agency%20Approval%20Document&DocLang=English&DocFormat=pdf&PartCntxt=776273-2
ENG_CS_AMPSEAL_CONNECTOR_SERIES_A.pdf	https://www.te.com/commerce/DocumentDelivery/DDEController?Action=srchrtrv&DocNm=AMPSEAL_CONNECTOR_SERIES&DocType=Catalog%20Section&DocLang=English&DocFormat=pdf&PartCntxt=776273-2
ENG_CS_ict_ampseal_cat_a4_1-1773979-2_en_A.pdf	https://www.te.com/commerce/DocumentDelivery/DDEController?Action=srchrtrv&DocNm=ict_ampseal_cat_a4_1-1773979-2_en&DocType=Catalog%20Section&DocLang=English&DocFormat=pdf&PartCntxt=776273-2
ENG_CVM_CVM_776273-2_E.2d_dxf.zip	https://www.te.com/commerce/DocumentDelivery/DDEController?Action=srchrtrv&DocNm=CVM_776273-2&DocType=Customer%20View%20Model&DocLang=English&DocFormat=2d_dxf.zip&PartCntxt=776273-2
ENG_CVM_CVM_776273-2_E.3d_igs.zip	https://www.te.com/commerce/DocumentDelivery/DDEController?Action=srchrtrv&DocNm=CVM_776273-2&DocType=Customer%20View%20Model&DocLang=English&DocFormat=3d_igs.zip&PartCntxt=776273-2
ENG_CVM_CVM_776273-2_E.3d_stp.zip	https://www.te.com/commerce/DocumentDelivery/DDEController?Action=srchrtrv&DocNm=CVM_776273-2&DocType=Customer%20View%20Model&DocLang=English&DocFormat=3d_stp.zip&PartCntxt=776273-2
ENG_DS_1-1773950-7_A.pdf	https://www.te.com/commerce/DocumentDelivery/DDEController?Action=srchrtrv&DocNm=1-1773950-7&DocType=Data%20Sheet&DocLang=English&DocFormat=pdf&PartCntxt=776273-2
ENG_DS_1-1773962-8_A.pdf	https://www.te.com/commerce/DocumentDelivery/DDEController?Action=srchrtrv&DocNm=1-1773962-8&DocType=Data%20Sheet&DocLang=English&DocFormat=pdf&PartCntxt=776273-2
ENG_DS_1-1773979-2_A.pdf	https://www.te.com/commerce/DocumentDelivery/DDEController?Action=srchrtrv&DocNm=1-1773979-2&DocType=Data%20Sheet&DocLang=English&DocFormat=pdf&PartCntxt=776273-2
ENG_SS_108-1329_E1.pdf	https://www.te.com/commerce/DocumentDelivery/DDEController?Action=srchrtrv&DocNm=108-1329&DocType=Specification%20Or%20Standard&DocLang=English&DocFormat=pdf&PartCntxt=776273-2
ENG_SS_114-16016_S3.pdf	https://www.te.com/commerce/DocumentDelivery/DDEController?Action=srchrtrv&DocNm=114-16016&DocType=Specification%20Or%20Standard&DocLang=English&DocFormat=pdf&PartCntxt=776273-2
ENG_SS_408-3229_F.pdf	https://www.te.com/commerce/DocumentDelivery/DDEController?Action=srchrtrv&DocNm=408-3229&DocType=Specification%20Or%20Standard&DocLang=English&DocFormat=pdf&PartCntxt=776273-2
ENG_SS_502-1266_A.pdf	https://www.te.com/commerce/DocumentDelivery/DDEController?Action=srchrtrv&DocNm=502-1266&DocType=Specification%20Or%20Standard&DocLang=English&DocFormat=pdf&PartCntxt=776273-2
Fastening Type	Latch Holder
Features	-
Housing Material	Glass-Filled PBT
HTSUS编码	8536.69.8000
Insulation Material	Polybutylene Terephthalate (PBT)
JPHTS	853890000
Mating Alignment	With
Mating Alignment Type	Keyed
Mating Pin Diameter	1.3 mm [ .051 in ]
Mixed & Hybrid Connector	No
MXHTS	8538900100
Nominal Voltage Architecture (V)	250
Number of Rows	3
Operating Voltage (VAC)	250
Packaging Method	Tray
Packaging Quantity	56
Primary Locking Feature	Integrated in Housing
Primary Product Color	Natural
Product Features & Characteristics	Select All
Product Length	35.4 mm [ 1.394 in ]
Product Width	33.6 mm [ 1.323 in ]
REACH-SVHC	Dodecamethylcyclohexasiloxane [D6] (540-97-6)、Decamethylcyclopentasiloxane [D5] (541-02-6)、Octamethylcyclotetrasiloxane [D4] (556-67-2)
REACH状态	REACH Unaffected
Row Spacing	0.157" (4.00mm)
Row-to-Row Spacing	4 mm [ .157 in ]
Serviceable	Yes
Standard Pack Qty	56
Strain Relief	Without
TARIC	8538909999
Terminal Position Assurance	Yes
TE内部描述	14POS,AMPSEAL,SOC HSG ASSY,SLD,COD 2
TE内部编号	776273-2
UL Flammability Rating	UL 94V-0
USHTS	8538906000
中心线（间距）	.157 in
主体颜色	自然色
主要锁定特性	外壳集成
交期	91 Days
产品名称	776273-2 (TE Connectivity)
产品宽度	1.323 in
产品描述	Housing for Female Terminals, Wire-to-Board, 14 Position, .157 in [4 mm] Centerline, Sealable, Natural, Wire & Cable, Power & Signal, AMPSEAL
产品状态	Id：0；Status：Active
产品长度	1.394 in
产地	美国/USA
公端/母端	插座
出线角度	180°
制造商交期（周）	13
包装方式	-
单位重量（kg）	0.017462
参考单价（USD）	6.88
可密封性	是
可用库存	669
可维修	是
品名	塑壳
品牌归属地	国际
基本分类	连接器
外壳材料	PBT GF
子品牌	TE Connectivity
官方产品图片1	https://www.te.com/content/dam/te-com/catalog/part/007/762/732/776273-2-t1.jpg/jcr:content/renditions/product-details.png
封装数量	280
工作温度范围	257 °F、-40 – 257 °F
工作电压	250 VAC
应力消除	不带
排数	3
接合对准	带有
接合对准类型	键控
接合插针直径	.051 in
数据手册	https://www.te.com/commerce/DocumentDelivery/DDEController?Action=srchrtrv&DocNm=2293782&DocType=Customer+Drawing&DocLang=English
替代型号	98T7-00068（JiDC(济德)）
标称电压架构	250 V
混合型连接器	否
湿敏等级	1 (Unlimited)
电路应用	电源和信号
端子位置保证	是
端子大小	1.3mm
能够保证连接器位置	是
行距	3.99mm
贸泽编号	571-776273-2
连接器和壳体类型	母端子护套
连接器和端子端接到	电线和电缆
连接器和键控代码	2
连接器形状	矩形
连接器系统	线到板
连接器高度	1.362 in
针位数	14
阻燃等级	UL94 V-0
零件编号	776273-2
防护等级	IP6K7 \| IP6K9K
安装风格	Free Hanging (In-Line)
工作温度（Max）	125 °C [ 257 °F ]
包装	Bulk
芯数	14
额定电流	17 A
系列	AMPSEAL
端接方式	Crimp

品牌：TE Connectivity 产品类别：汽车连接器护套产品系列：AMPSEAL

同品牌、系列或类别的相似产品（不代表兼容或可替代）

TE Connectivity 5-965906-1 连接器端子 TE Connectivity 936207-1 连接器胶壳 TE Connectivity 3-1534127-1 连接器胶壳 TE Connectivity 2822357-1 连接器密封件 TE Connectivity 2822354-1 连接器密封件 TE Connectivity 963142-3 连接器密封件 TE Connectivity 1564411-7 连接器配件 TE Connectivity 1703278-2 连接器端子

已核验询价信息

包装方式: -
Packaging: Bulk
最小订购量: 1

制造商及授权来源记录

产品资料

776273-2

776273-2 是 TE Connectivity Deutsch Connectors 的 Automotive Housings产品。本页汇总官方技术资料、贸易合规、包装和国内供货信息。

品牌

TE Connectivity Deutsch Connectors

制造商

TE Connectivity Deutsch Connectors

产品类别

Automotive Housings

技术参数

主体颜色	自然色
公端/母端	插座
包装方式	-
品牌归属地	国际
安装类型	电缆安装(自由悬挂)
排数	3
系列	AMPSEAL
行距	3.99mm
针位数	14
防护等级	IP67
阻燃等级	UL94 V-0
TE内部编号	776273-2
中心线（间距）	.157 in
主要锁定特性	外壳集成
产品宽度	1.323 in
产品长度	1.394 in
出线角度	180°
分类	汽车连接器护套
可密封性	是
可维修	是
外壳材料	PBT GF
子品牌	TE Connectivity
封装数量	280
工作温度范围	257 °F、-40 – 257 °F
工作电压	250 VAC
应力消除	不带
接合对准	带有
接合对准类型	键控
接合插针直径	.051 in
描述	14POS,AMPSEAL,SOC HSG ASSY,SLD,COD 2
标称电压架构	250 V
混合型连接器	否
电路应用	电源和信号
端子位置保证	是
端子大小	1.3mm
能够保证连接器位置	是
连接器和壳体类型	母端子护套
连接器和端子端接到	电线和电缆
连接器和键控代码	2
连接器形状	矩形
连接器系统	线到板
连接器高度	1.362 in
零件编号	776273-2
额定电流	17 A
Packaging	Bulk
Standard Pack Qty	56
Connector Type	Plug
Contact Type	Female Socket
Number of Positions	14
Pitch	0.157" (4.00mm)
Number of Rows	3
Row Spacing	0.157" (4.00mm)
Mounting Type	Free Hanging (In-Line)
Contact Termination	Crimp
Fastening Type	Latch Holder
Color	Natural
Features	-
Insulation Material	Polybutylene Terephthalate (PBT)
Operating Temperature	-40°C ~ 125°C
单位重量（kg）	0.017462
Nominal Voltage Architecture ( V)	250
Connector & Housing Type	Housing for Female Terminals
Number Of Positions	14
Sealable	Yes
Operating Temperature Range	-40 – 125 °C [ -40 – 257 °F ]
Product Features & Characteristics	Select All
Connector Shape	Rectangular
Mixed & Hybrid Connector	No
Primary Locking Feature	Integrated in Housing
Connector System	Wire-to-Board
Connector & Contact Terminates To	Wire & Cable
Number Of Rows	3
Operating Voltage ( V A C)	250
Cable Exit Angle (°)	180
Primary Product Color	Natural
Connector & Keying Code	2
Contact Type	Socket
Contact Size	1.3mm
Mating Pin Diameter	1.3 mm [ .051 in ]
Contact Current Rating ( Max) ( A)	17
Mating Alignment	With
Mating Alignment Type	Keyed
Terminal Position Assurance	Yes
Strain Relief	Without
Connector Mounting Type	Free-Hanging (In-Line)
Housing Material	Glass-Filled PBT
Centerline ( Pitch)	4 mm [ .157 in ]
Connector Height	34.6 mm [ 1.362 in ]
Product Length	35.4 mm [ 1.394 in ]
Product Width	33.6 mm [ 1.323 in ]
Row-To- Row Spacing	4 mm [ .157 in ]
Operating Temperature ( Max)	125 °C [ 257 °F ]
Circuit Application	Power
U L Flammability Rating	UL 94V-0
I P Rating	IP6K7 \| IP6K9K
Packaging Method	Tray
Packaging Quantity	56
Serviceable	Yes
Connector Position Assurance Capable	Yes

采购与包装

最小订购量	1
订购倍数	1
工厂库存	0

合规信息

RoHS状态	ROHS3 Compliant
REACH状态	REACH Unaffected
湿敏等级	1 (Unlimited)
ECCN	EAR99
HTSUS编码	8536.69.8000
REACH-SVHC	Dodecamethylcyclohexasiloxane [D6] (540-97-6)、Decamethylcyclopentasiloxane [D5] (541-02-6)、Octamethylcyclotetrasiloxane [D4] (556-67-2)
CNHTS	8538900000
TARIC	8538909999
CAHTS	8538903900
USHTS	8538906000
JPHTS	853890000
MXHTS	8538900100
BRHTS	85389090
Country of Origin	Mexico
Assembly Country of Origin	Not available
Country of Diffusion	Not available

其他信息

产地	美国/USA批量参考批次：
品名	塑壳

参数来自已配置的数据源，仅供选型参考；订购前请以制造商最新资料为准。
