产品资料
828907-1
828907-1 是 TE Connectivity / AMP 的 Automotive Housings产品。本页汇总官方技术资料、贸易合规、包装和国内供货信息。
品牌
TE Connectivity / AMP
制造商
TE Connectivity / AMP
产品类别
Automotive Housings
技术参数
| Standard Pack Qty | 54 |
|---|---|
| 单位重量（kg） | 0.056699 |
| Nominal Voltage Architecture ( V) | 12 |
| Connector & Housing Type | Housing for Female Terminals |
| Number Of Positions | 55 |
| Sealable | Yes |
| Operating Temperature Range | -40 – 130 °C [ -40 – 266 °F ] |
| Product Features & Characteristics | Select All |
| Connector Shape | Rectangular |
| Mixed & Hybrid Connector | No |
| Primary Locking Feature | Locking Lance |
| Connector System | Wire-to-Board |
| Connector & Contact Terminates To | Wire & Cable |
| Number Of Rows | 3 |
| Operating Voltage ( V D C) | 12 |
| Cable Exit Angle (°) | 90 |
| Primary Product Color | Black |
| Connector & Keying Code | Neutral |
| Contact Type | Receptacle |
| Contact Size | 2.8mm |
| Mating Tab Width | 2.8 mm [ .11 in ] |
| Contact Current Rating ( Max) ( A) | 30 |
| Mating Alignment | With |
| Mating Alignment Type | Polarization |
| Terminal Position Assurance | No |
| Strain Relief | With |
| Connector Mounting Type | Free-Hanging (In-Line) |
| Housing Material | PBTP GV 15 |
| Centerline ( Pitch) | 5 mm [ .197 in ] |
| Connector Height | 40.25 mm [ 1.585 in ] |
| Product Length | 52.55 mm [ 2.069 in ] |
| Product Width | 36 mm [ 1.417 in ] |
| Row-To- Row Spacing | 6 mm [ .24 in ] |
| Operating Temperature ( Max) | 130 °C [ 266 °F ] |
| Circuit Application | Power |
| U L Flammability Rating | UL 94HB |
| Packaging Method | Carton |
| Serviceable | No |
| Connector Position Assurance Capable | No |
采购与包装
| 最小订购量 | 1 |
|---|---|
| 订购倍数 | 1 |
合规信息
| CNHTS | 8538900000 |
|---|---|
| TARIC | 8547200090 |
| CAHTS | 8538909090 |
| USHTS | 8538908180 |
| JPHTS | 853890000 |
| BRHTS | 85389090 |
| ECCN | EAR99 |
| Country of Origin | Hungary |
| Assembly Country of Origin | Not available |
| Country of Diffusion | Not available |
| RoHS状态 | RoHS Compliant |
参数来自已配置的数据源，仅供选型参考；订购前请以制造商最新资料为准。
