33012-2004

描述: MX150 Female Terminal for Mat-Sealed Connectors, Tin Plating, Grip Code M3, Preferred Terminal for use in Sealed Application with 0.35-0.50mm², Right Reel Payoff, Contact Material Thickness 0.30mm²
参数: 线径-mm²: 0.35 to 0.5 mm² 公端/母端: 母端

¥ 0.30

包装
- 个
- 盘
- 箱

加入购物车

添加到心愿单

条款及条件细则
30 天退款保证
送货：2 至 3 个工作天

33012-2004

33012-2004 是 Molex 的 Products>Connectors>PCB / Wire Connectors>Crimp Terminals产品。适用信息：Wire-to-Board、Wire-to-Wire、Automotive。本页汇总官方技术资料、贸易合规、包装和国内供货信息。

品牌

Molex

制造商

Molex

产品类别

Products>Connectors>PCB / Wire Connectors>Crimp Terminals

技术参数

Packaging	Reel
Standard Pack Qty	7000
单位重量（kg）	0.000391
接口性别	Female
Grip Code	M3
Material Metal	High Performance Alloy (HPA)
Material Plating Mating	Tin
Material Plating Termination	Tin
净重	0.391/g
Plating Min Mating	0.762µm
Plating Min Termination	2.540µm
Termination Interface Style	Crimp or Compression
Terminal Size	1.5
Wire Insulation Diameter	1.70mm max.
Wire Size Awg	N/A
Wire Size Mm	0.35-0.50

采购与包装

最小订购量	7000
订购倍数	7000
工厂库存	0
替代包装型号	33012-2004 (Cut Strip)、33012-2004 (Loose Piece)、33012-2004 (Mouser Reel)
包装类型	Reel

合规信息

CNHTS	8538900000
TARIC	8536699099
CAHTS	8536900020
USHTS	8536904000
JPHTS	8536900002
KRHTS	8536909010
BRHTS	85369090
ECCN	EAR99
Country of Origin	United States
Assembly Country of Origin	Not available
Country of Diffusion	Not available
RoHS状态	RoHS Compliant
GADSL/IMDS	Compliant with Exemption 34; 33
China RoHS	Green Image per SJ/T 11365-2006
EU ELV	Compliant per 2000/53/EC
Low-Halogen Status	Low-Halogen per IEC 61249-2-21
Prop65	Compliant per California Proposition 65
REACH SVHC	Not Contained per D(2025)7771-DC (04 Feb 2026)
EU RoHS	Compliant per EU 2015/863

配套关系

配套系列	33472 - MX150 Mat-Sealed Dual Row Female Connector Assemblies、33471 - MX150 Mat-Sealed Single Row Female Connector Assemblies、34985 - MX150 Hybrid Mat-Sealed Female Connector Assemblies、300361 - MX150 Mid-Voltage Mat-Sealed Female Connector Assemblies、300363 - MX150 Mid-Voltage Mat-Sealed Female Connector Assemblies、303367

其他信息

产品状态	Active
原产国	CN,US

参数来自已配置的数据源，仅供选型参考；订购前请以制造商最新资料为准。
