Summary: JST XADRP-14V appears in JST's official XAD connector material and on the local catalogue as a connector-housing record. This guide shows how to turn that record into a controlled documentation checklist for a wire-to-wire connector enquiry. It does not approve a counterpart, contact, wire, crimp process, retainer, assembly, replacement or compatibility.
Begin with the exact XADRP-14V record
The JST XADRP-14V product page is the site-level starting point. Capture the complete identifier, local URL, source date and catalogue wording before copying anything into an RFQ, drawing note or build packet. The page describes the item as a JST connector housing. That makes it a useful navigation record, but not a complete interface definition.
JST's official XAD document lists XADRP-14V in the XAD housing tables. The document also describes the XAD family as 2.5 mm pitch, disconnectable crimp-style wire-to-wire connectors. Those statements are dated manufacturer material for research; they do not establish the parts, process or validation approved for a particular harness.
Keep catalogue facts and project decisions separate
A catalogue page can preserve a part number and direct a reviewer to manufacturer material. A project release needs more: the exact mating-side identifier, contact version, wire construction, applicable controlled documents, tooling or process evidence, inspection requirements and approval owner. It also needs a dated record of which source was consulted and which questions remain unresolved. Do not fill those fields with a familiar family name, a product image or a prior build. Record every missing item as a question with an owner and a source target.
- Catalogue observation: save the full model, local page address and official-source revision or access date.
- Interface evidence: identify each proposed counterpart, contact and retention item by its own complete manufacturer number.
- Process evidence: retain the controlled crimp, tooling, inspection and release documents applicable to the actual build.
- Decision evidence: record who confirms the complete configuration and under which project requirement.
Use XAD as a research cue, not a blanket relationship
The site's XAD Connector series page and JST brand page are useful places to organise a source trail. They do not turn any two listings into a mating, replacement or application relationship. The JST XADS-14V-K product listing is therefore treated here as an independent local catalogue record. It is not presented as a counterpart, accessory or alternative for XADRP-14V.
Build a documentation-first RFQ
A clear connector enquiry includes the exact requested part number, an application description, quantity basis, target date, packaging requirement and the controlled documents already available. It should name the evidence still needed instead of guessing it. For an XADRP-14V request, useful open fields may include the intended connector-system configuration, each related part number, document revision, wire and process requirements, and the project authority that will accept the final assembly. This language makes a request actionable without promising stock, lead time, price, fit or performance.
FAQ
Does the XADRP-14V catalogue record prove a complete connector assembly?
No. It identifies one record and its research sources. Verify every proposed related part and the actual build requirements from current controlled documents for the full configuration.
Can 2.5 mm pitch wording be used as an installation instruction?
No. It is manufacturer family information, not a wiring, crimping, panel, clearance or inspection instruction for a specific project.
May a nearby XAD listing be substituted in an RFQ?
Not from this article. Treat a different listing as a separate record until the responsible process verifies the complete proposed configuration against applicable controlled data.
Conclusion
For JST XADRP-14V, start with the exact local record and the official XAD material, then keep catalogue facts, open questions and approved project evidence visibly separate. That discipline reduces unsupported connector assumptions. For help preparing a part-number-led enquiry, contact Lianxinlian Electronics with the full model, application context and available source documents.
Manufacturer Sources
Use the current official sources and released project documents to confirm the exact configuration before purchase, production or design release.
