产品技术规格
| 1 | 0.178 |
|---|---|
| 160000 | 0.097 |
| 20 | 0.17 |
| 40000 | 0.101 |
| 8000 | 0.104 |
| 80000 | 0.098 |
| Applicable wire size | 0.22-0.5mm2 |
| batch | ZK |
| Cable size（mm 2） | 0.22〜0.5 |
| Contact resistance | Initial8mΩ Max. after durability tests16mΩ Max. |
| Contact resistance (after durability tests) | 16mΩ Max. |
| Contact resistance (Initial) | 8mΩ Max. |
| Country of Origin | Japan |
| Insulation resistance | 100MΩ Min. |
| Leak current | 50μA Max. |
| Male/Female | M |
| Materials | Brass |
| Mating parts | 8100-3455(TS sealed series) |
| Product | Terminals |
| Product drawing | https://prd.sws.co.jp/components/products/draw_img/81003617.pdf |
| RoHS Compliant | Yes |
| Sealed/Unsealed | sealed |
| Size | M |
| Surface treatment | Tin-plated |
| Tab Size | 0.64mm(025) |
| Wire Gauge Range | 22-20AWG |
| 主体材料 | Brass |
| 交期 | 14-16周 |
| 产品名称 | 8100-3617 (SUMITOMO) |
| 产地 | 日本/JPN |
| 公端/母端 | 公端 |
| 品名 | 盘装端子 |
| 品牌归属地 | 国际 |
| 基本分类 | 连接器 |
| 官方产品图片1 | https://prd.sws.co.jp/components/products/photo_img/81003617.jpg |
| 官方产品图片2 | https://prd.sws.co.jp/components/products/photo_img/61884797.jpg |
| 官方产品图片3 | https://prd.sws.co.jp/components/products/photo_img/61884920.jpg |
| 官方产品图片4 | https://prd.sws.co.jp/components/products/photo_img/61880706.jpg |
| 官方产品图片5 | https://prd.sws.co.jp/components/products/photo_img/61880779.jpg |
| 年份批次 | 202604 |
| 接触电阻 | Initial8mΩ Max. after durability tests16mΩ Max. |
| 插片宽度 | 0.64mm |
| 是否密封 | sealed |
| 替代型号 | 91S3-00026（JiDC(济德)） |
| 漏电流 | 50μA Max. |
| 相关产品:外壳 | 6188-4797,6188-4920,6188-0706,6188-0779,6188-0696,6188-4914,6188-5103 |
| 相关产品:电线密封 | 7165-1043,7165-1312,7165-1198,7165-1199,7165-1423 |
| 线径-mm² | 0.22 to 0.5 mm² |
| 绝缘电阻 | 100MΩ Min. |
| 触头镀层 | 锡 |
| 工作温度 | -40℃～120℃ |
| 包装 | Reel |
| 系列 | TS sealed series |
Related product information
Manufacturer and authorized source records
Product information
Sumitomo Wiring Systems 8100-3617 Connector Terminal
8100-3617 is a Sumitomo Wiring Systems electronic component. Review the verified specifications, packaging, compliance and availability information before ordering.
Part number
8100-3617
Brand
Sumitomo Wiring Systems
Series
TS Sealed Series
Technical specifications
| Gender | Male |
|---|---|
| Brand region | International |
| Series | TS sealed series |
| Wire size (mm²) | 0.22 to 0.5 mm² |
| Contact plating | Tin |
| Sealed/ Unsealed | sealed |
| Male/ Female | M |
| Tab Size | 0.64mm(025) |
| Size | M |
| Mating Parts | 8100-3455(TS sealed series) |
| Applicable Wire Size | 0.22-0.5mm2 |
| Materials | Brass |
| Surface Treatment | Tin-plated |
| Contact Resistance | Initial8mΩ Max. after durability tests16mΩ Max. |
| Leak Current | 50μA Max. |
| Insulation Resistance | 100MΩ Min. |
Specifications are provided for selection reference. Confirm the complete part number, packaging and latest manufacturer documentation before ordering.
