产品技术规格
| 889-1482-ND | Bulk |
|---|---|
| Amperage | 7.5A |
| Assembly Country of Origin | Not available |
| BRHTS | 85366990 |
| CAHTS | 8536690090 |
| CNHTS | 8538900000 |
| Connector Type | Plug |
| Contact Gender | Socket (Female) |
| Contacts Included | No |
| Contact Type | Female Socket |
| Contact Type (Pin/Socket) | Socket |
| Country of Diffusion | Not available |
| Country of Origin | Mexico |
| Dielectric Value | Dielectric withstanding voltage less than 2 milliamps current leakage @ 1500 volts AC |
| DigiKey编号 | 889-1482-ND |
| ECCN | EAR99 |
| Fastening Type | Latch Lock |
| Features | Sealed |
| Gender | Female |
| Housing Material | Thermoplastic |
| HTS | 8536698000 |
| HTSUS编码 | 8538.90.6000 |
| Insulation Material | Thermoplastic |
| Insulation Resistance | 1000 megohms at 25°C |
| JPHTS | 853669000 |
| Key Configuration | KEY-A CONFIGURATION STANDARD COLOR: GREY |
| KRHTS | 8536699000 |
| Mating Cycle Durability | >100 |
| Mating Part(s) | ATM04-12PA*, ATM13-12PA*, ATM15-12PA* Receptacle |
| Mounting Angle | Straight |
| MXHTS | 85366999 |
| No. of Positions | 12, A Key |
| Number of Rows | 2 |
| REACH SVHC | No |
| REACH状态 | REACH Unaffected |
| RoHS Compliant | Yes |
| Row Spacing | - |
| Seal Diameter | 1.35mm (.053") - 3.05mm (.120") |
| Sealed / Unsealed | Sealed |
| Seal Material | Silicone Elastomer |
| Shape | Rectangular |
| Standard Pack Qty | 200 |
| TARIC | 8547200090 |
| Type | 12-Way |
| USHTS | 8536698000 |
| Wedge Part# | AWM-12S |
| Wire Gauge Max | 16 AWG |
| Wire Gauge Min | 22 AWG |
| Wire Gauge Range | 22 AWG to 16 AWG |
| Wire Range | 16-22 AWG (1.5-0.35mm²) |
| 交期 | 112 Days |
| 产品名称 | ATM06-12SA (Amphenol) |
| 产品状态 | Id：0；Status：Active |
| 制造商交期（周） | 16 |
| 参考单价（USD） | 1.78 |
| 可用库存 | 10797 |
| 数据手册 | https://www.amphenol-sine.com/pdf/catalog/ATM-Flyer-2016.pdf |
| 替代型号 | 92A0-00069（JiDC(济德)）、DTM06-12SA（DEUTSCH） |
| 湿敏等级 | 1 (Unlimited) |
| 贸泽编号 | 654-ATM06-12SA |
| 防护等级 | IP67 (in mated condition) |
| 最低工作温度 | - 55 C |
| 安装风格 | Free Hanging (In-Line) |
| 包装 | Bulk |
| 芯数 | 12 |
| 额定电流 | 7.5 A |
| 额定电压 | 250V |
| 系列 | ATM Series™ |
| 端接方式 | Crimp |
| 最高工作温度 | + 125 C |
Related product information
Similar products for discovery (not a compatibility or replacement claim)
Verified inquiry information
- Minimum order quantity
- 1
Manufacturer and authorized source records
Product information
Amphenol ATM06-12SA Electrical Connector
ATM06-12SA is a Amphenol Circular Connectors. Review the verified specifications, packaging, compliance and availability information before ordering.
Part number
ATM06-12SA
Brand
Amphenol
Category
Circular Connectors
Technical specifications
| Standard Pack Qty | 200 |
|---|---|
| Connector Type | Plug |
| Contact Type | Female Socket |
| Number of Positions | 12 |
| Pitch | - |
| Number of Rows | 2 |
| Row Spacing | - |
| Mounting Type | Free Hanging (In-Line) |
| Contact Termination | Crimp |
| Fastening Type | Latch Lock |
| Color | Gray |
| Features | Sealed |
| Insulation Material | Thermoplastic |
| Operating Temperature | -55°C ~ 125°C |
Ordering and packaging
| Minimum order quantity | 1 |
|---|---|
| Order multiple | 1 |
| Factory stock | 0 |
Compliance information
| RoHS status | ROHS3 Compliant |
|---|---|
| REACH status | REACH Unaffected |
| Moisture sensitivity level | 1 (Unlimited) |
| ECCN | EAR99 |
| CNHTS | 8538900000 |
| CAHTS | 8536690090 |
| USHTS | 8536698000 |
| JPHTS | 853669000 |
| KRHTS | 8536699000 |
| TARIC | 8547200090 |
| MXHTS | 85366999 |
| BRHTS | 85366990 |
| Country of Origin | Mexico |
| Assembly Country of Origin | Not available |
| Country of Diffusion | Not available |
Specifications are provided for selection reference. Confirm the complete part number, packaging and latest manufacturer documentation before ordering.
