Product information
Bourns CD1206-B240 Electronic Component
CD1206-B240 is a Bourns electronic component. Review the verified specifications, packaging, compliance and availability information before ordering.
Part number
CD1206-B240
Brand
Bourns
Series
CD1206-B2
Technical specifications
| Brand region | International |
|---|---|
| Series | CD1206-B2 |
| IRRM (mA) | 500 |
| Length (mm) | 3.4 |
| RΘJA (°C/W) | 75 |
| Tj High (°C) | 125 |
| Tj Low (°C) | -55 |
| Width (mm) | 1.9 |
| Packaging | Reel |
| Standard Pack Qty | 3000 |
| Technology | Schottky |
| Voltage - DC Reverse (Vr) (Max) | 40 V |
| Current - Average Rectified (Io) | 2A |
| Voltage - Forward (Vf) (Max) @ If | 500 mV @ 2 A |
| Speed | Fast Recovery =< 500ns, > 200mA (Io) |
| Current - Reverse Leakage @ Vr | 500 µA @ 40 V |
| Capacitance @ Vr, F | - |
| Mounting Type | Surface Mount |
| Package / Case | Chip, Concave Terminals |
| Supplier Device Package | 1206 |
| Operating Temperature - Junction | -55°C ~ 125°C |
| Unit weight (kg) | 5.8e-05 |
Ordering and packaging
| Minimum order quantity | 1 |
|---|---|
| Order multiple | 1 |
| Factory stock | 0 |
Compliance information
| RoHS status | ROHS3 Compliant |
|---|---|
| REACH status | REACH Affected |
| Moisture sensitivity level | 1 (Unlimited) |
| ECCN | EAR99 |
| REACH-SVHC | Lead (7439-92-1) |
| CNHTS | 8541100000 |
| CAHTS | 8541100090 |
| USHTS | 8541100080 |
| JPHTS | 854110090 |
| KRHTS | 8541109000 |
| TARIC | 8541100000 |
| MXHTS | 8541100199 |
| BRHTS | 85411029 |
| Country of Origin | Taiwan, China |
| Assembly Country of Origin | Not available |
| Country of Diffusion | Not available |
Specifications are provided for selection reference. Confirm the complete part number, packaging and latest manufacturer documentation before ordering.
