产品技术规格
| 1 | 1.495 |
|---|---|
| 1250 | 0.771 |
| 20 | 1.424 |
| 250 | 0.793 |
| 2500 | 0.749 |
| 2D PDF | https://www.ket.com/resources/web/MG651359-5/MG651359-5_2d.pdf |
| 5000 | 0.734 |
| batch | N |
| Certification | TUV, TS16949, ISO14001, RoHS |
| Classified Parts | Carcasa |
| Color | Black |
| Contact Resistance | 3mΩ MAX (Initial) |
| Dimensions | 20.15*37.2*22.7 |
| Insulation Resistance | DC 500V 100MΩ MIN |
| Male/Female | Macho |
| Material | PBT+G, PA66+GF |
| Material Type | PBT |
| Mating Connector | MG641362 |
| Mating Tab Width(in) | .090 |
| Mating Terminal | ST740686-3, ST740687-3, ST740688-3 |
| Number of Poles | 3 |
| Primary Locking Type | HSG Lance |
| Sealed | YES |
| Tab Size | 2.3mm(090) |
| Terminal Transmits(A) | 10 |
| TPA | YES |
| Unsealed/Sealed | Sellado |
| Wire Gauge Range | 18-20 AWG |
| Wire Range | avs(cavs) 0.3-0.5,avs(cavs) 0.85-1.25,avss 2.0 |
| 主体颜色 | 黑色 |
| 主要锁定类型 | HSG Lance |
| 交期 | 14-16周 |
| 产品名称 | MG651359-5 (KET) |
| 产品描述 | 090II WP 3M CONN'T ASSY |
| 产品等级 | 车规级 |
| 产品间距 | 6.00mm |
| 产地 | 韩国/KOR |
| 品名 | 塑壳 |
| 品牌归属地 | 国际 |
| 基本分类 | 连接器 |
| 官方产品图片1 | https://www.ket.com/cm/fileDownMan.ket?attcFilSn=141105 |
| 尺寸 | 20.15*37.2*22.7 |
| 接触电阻 | 3mΩ MAX (Initial) |
| 插片宽度(in) | .090 |
| 是否密封 | YES |
| 替代型号 | 92K6-00022（JiDC(济德)） |
| 材料类型 | PBT |
| 线径-mm² | AVS(CAVS) 0.3-0.5,AVS(CAVS) 0.85-1.25,AVSS 2.0 |
| 绝缘电阻 | DC 500V 100MΩ MIN |
| 配套端子 | ST740686-3、ST740687-3、ST740688-3 |
| 配套连接器 | MG641362 |
| 针位数 | 3 |
| 工作温度 | -40℃～120℃ |
| 间距（mm） | 6 |
| 额定电流 | 10A |
| 系列 | 090 II SERIES |
Related product information
Similar products for discovery (not a compatibility or replacement claim)
Manufacturer and authorized source records
Product information
Korea Electric Terminal MG651359-5 Electrical Connector
MG651359-5 is a Korea Electric Terminal Wire-to-Wire Connectors. Review the verified specifications, packaging, compliance and availability information before ordering.
Part number
MG651359-5
Brand
Korea Electric Terminal
Category
Wire-to-Wire Connectors
Series
090 II Series
Technical specifications
| Pitch | 6.00mm |
|---|---|
| Brand region | International |
| Series | 090 II SERIES |
| Number of positions | 3 |
| TPA | YES |
| Wire size (mm²) | AVS(CAVS) 0.3-0.5,AVS(CAVS) 0.85-1.25,AVSS 2.0 |
| Part Number | MG651359-5 |
| Series | 090 II SERIES |
| Dimensions | 20.15*37.2*22.7 |
| Material Type | PBT |
| Sealed | YES |
| Color | Black |
| Primary Locking Type | HSG Lance |
| T P A | YES |
| Number Of Poles | 3 |
| Mating Terminal | ST740686-3, ST740687-3, ST740688-3 |
| Mating Connector | MG641362 |
| Pitch(Mm) | 6 |
| Mating Tab Width(In) | .090 |
| Wire Range | avs(cavs) 0.3-0.5,avs(cavs) 0.85-1.25,avss 2.0 |
| Insulation Resistance | DC 500V 100MΩ MIN |
| Contact Resistance | 3mΩ MAX (Initial) |
| Terminal Transmits( A) | 10 |
Specifications are provided for selection reference. Confirm the complete part number, packaging and latest manufacturer documentation before ordering.
