产品技术规格
| 1 | 0.139 |
|---|---|
| 20 | 0.133 |
| 2D PDF | https://www.ket.com/resources/web/ST740673-3/ST740673-3_2d.pdf |
| 4500 | 0.068 |
| batch | ZK |
| Contact Resistance | 3mΩ MAX |
| Dimensions | 26.7*2.9*2.9 |
| Insulation Range | 2.2-2.6 |
| Material Type | Brass |
| Mating Tab Width(in) | .090 |
| Plating | Pre-Tin |
| Sealed | NO |
| Tab Thickness(mm) | 0.64 |
| Terminal Transmits(A) | 10 |
| Terminal Type | Straight-Side |
| Wire Range | avs[cavs]0.85-1.25 |
| 交期 | 15-16周 |
| 产品名称 | ST740673-3 (KET) |
| 产品描述 | 090II MALE TERMINAL(M) |
| 产品等级 | 车规级 |
| 产地 | 韩国/KOR |
| 品名 | 盘装端子 |
| 品牌归属地 | 国际 |
| 基本分类 | 连接器 |
| 官方产品图片1 | https://www.ket.com/cm/fileDownMan.ket?attcFilSn=139220 |
| 尺寸 | 26.7*2.9*2.9 |
| 年份批次 | 202604 |
| 接触电阻 | 3mΩ MAX |
| 插片厚度 | 0.64mm |
| 插片宽度 | 2.29mm |
| 是否密封 | NO |
| 替代型号 | 91K6-00019（JiDC(济德)） |
| 材料类型 | Brass |
| 端子类型 | Straight-Side |
| 线径-mm² | 0.85 to 1.25 mm² |
| 绝缘范围 | 2.2-2.6 |
| 触头镀层 | 锡 |
| 额定电流 | 10A |
| 系列 | 090 II SERIES |
Related product information
Similar products for discovery (not a compatibility or replacement claim)
Manufacturer and authorized source records
Product information
KET ST740673-3 Connector Terminal
ST740673-3 is a KET Automotive Terminals. Review the verified specifications, packaging, compliance and availability information before ordering.
Part number
ST740673-3
Brand
KET
Category
Automotive Terminals
Series
090 II Series
Technical specifications
| Brand region | International |
|---|---|
| Series | 090 II SERIES |
| Wire size (mm²) | 0.85 to 1.25 mm² |
| Contact plating | Tin |
| Part Number | ST740673-3 |
| Series | 090 II SERIES |
| Material Type | Brass |
| Dimensions | 26.7*2.9*2.9 |
| Plating | Pre-Tin |
| Sealed | NO |
| Tab Thickness(Mm) | 0.64 |
| Mating Tab Width(In) | .090 |
| Terminal Type | Straight-Side |
| Terminal Transmits( A) | 10 |
| Insulation Range | 2.2-2.6 |
| Wire Range | avs[cavs]0.85-1.25 |
| Contact Resistance | 3mΩ MAX |
Specifications are provided for selection reference. Confirm the complete part number, packaging and latest manufacturer documentation before ordering.
