TE Connectivity 1-1564416-1 Connector Housing
1-1564416-1 is a TE Connectivity Automotive Housings. Review the verified specifications, packaging, compliance and availability information before ordering.
Part number
1-1564416-1
Brand
TE Connectivity
Category
Automotive Housings
Technical specifications
| Packaging | Bulk |
|---|---|
| Standard Pack Qty | 250 |
| Unit weight (kg) | 0.024659 |
| Nominal Voltage Architecture ( V) | 12 | 24 | 48 |
| Connector & Housing Type | Housing for Male Terminals |
| Number Of Positions | 8 |
| Sealable | Yes |
| Operating Temperature Range | -40 – 140 °C [ -40 – 284 °F ] |
| Product Features & Characteristics | Select All |
| Connector Shape | Rectangular |
| Mixed & Hybrid Connector | No |
| Primary Locking Feature | On the Terminal |
| Connector System | Wire-to-Wire |
| Connector & Contact Terminates To | Wire & Cable |
| Number Of Rows | 2 |
| Operating Voltage ( V D C) | 60 |
| Cable Exit Angle (°) | 90 | 180 |
| Primary Product Color | Black |
| Connector & Keying Code | A |
| Contact Type | Tab |
| Contact Size | 1.6mm |
| Mating Tab Width | 1.6 mm [ .063 in ] |
| Contact Current Rating ( Max) ( A) | 10 |
| Mating Alignment | With |
| Mating Alignment Type | Keyed |
| Terminal Position Assurance | No |
| Connector Mounting Type | Free-Hanging (In-Line) |
| Housing Material | PBT GF30 |
| Centerline ( Pitch) | 4 mm [ .157 in ] |
| Connector Height | 39.8 mm [ 1.567 in ] |
| Product Length | 42.5 mm [ 1.673 in ] |
| Product Width | 47.05 mm [ 1.852 in ] |
| Row-To- Row Spacing | 6.9 mm [ .272 in ] |
| Operating Temperature ( Max) | 140 °C [ 284 °F ] |
| Circuit Application | Power |
| U L Flammability Rating | UL 94V-0 |
| I P Rating | IP67 |
| Packaging Method | Carton |
| Packaging Quantity | 250 |
| Serviceable | Yes |
Ordering and packaging
| Minimum order quantity | 1 |
|---|---|
| Order multiple | 1 |
Compliance information
| CNHTS | 8536901100 |
|---|---|
| TARIC | 8547200090 |
| CAHTS | 8538903900 |
| USHTS | 8538906000 |
| JPHTS | 853890000 |
| MXHTS | 8538900100 |
| BRHTS | 85389090 |
| ECCN | EAR99 |
| Country of Origin | Morocco |
| Assembly Country of Origin | Not available |
| Country of Diffusion | Not available |
| RoHS status | RoHS Compliant |
Specifications are provided for selection reference. Confirm the complete part number, packaging and latest manufacturer documentation before ordering.
