产品技术规格
| 1 | 1.946 |
|---|---|
| 17000 | 1.066 |
| 20 | 1.853 |
| 3D_CVM_CVM_1-480710-0_CC1.pdf | https://www.te.com/commerce/DocumentDelivery/DDEController?Action=srchrtrv&DocNm=CVM_1-480710-0&DocType=Customer%20View%20Model&DocLang=3D&DocFormat=pdf&PartCntxt=1-480710-0 |
| 4250 | 1.119 |
| 850 | 1.151 |
| 8500 | 1.087 |
| A1462-ND | Bulk |
| Assembly Country of Origin | Not available |
| batch | ZK |
| BRHTS | 85389090 |
| CAHTS | 8538903900 |
| Centerline (Pitch) | 6.35 mm [.25 in] |
| Circuit Application | Power & Signal |
| CNHTS | 8547200000 |
| Color | Natural |
| Compatible With Agency/Standards Products | CSA | UL | VDE |
| Compatible With Approved Standards Products | UL E28476 |
| Connector & Contact Terminates To | Wire & Cable |
| Connector Height | 27.43 mm [ 1.08 in ] |
| Connector & Housing Type | Plug |
| Connector Mounting Type | Free-Hanging (In-Line) |
| Connector Product Type | Housing |
| Connector System | Wire-to-Board | Wire-to-Wire |
| Connector Type | Plug |
| Contact Layout | Matrix |
| Contact Retention Within Housing | Without |
| Country of Diffusion | Not available |
| Country of Origin | China |
| CSA Rating | Certified | LR 7189 |
| CSA 等级 | LR 7189 |
| Customer Drawing | https://www.te.com/commerce/DocumentDelivery/DDEController?Action=srchrtrv&DocNm=480710&DocType=Customer%20Drawing&DocLang=English&DocFormat=pdf&PartCntxt=1-480710-0 |
| DigiKey编号 | A1462-ND |
| ECCN | EAR99 |
| ENG_AAD_UL_CERT_E28476_19760715_C1_13.pdf | https://www.te.com/commerce/DocumentDelivery/DDEController?Action=srchrtrv&DocNm=UL_CERT_E28476_19760715_C1&DocType=Agency%20Approval%20Document&DocLang=English&DocFormat=pdf&PartCntxt=1-480710-0 |
| ENG_CS_82181_SOFTSHELL_STANDARD_DENSITY_2603.pdf | https://www.te.com/commerce/DocumentDelivery/DDEController?Action=srchrtrv&DocNm=82181_SOFTSHELL_STANDARD_DENSITY&DocType=Catalog%20Section&DocLang=English&DocFormat=pdf&PartCntxt=1-480710-0 |
| ENG_CVM_CVM_1-480710-0_CC1.2d_dxf.zip | https://www.te.com/commerce/DocumentDelivery/DDEController?Action=srchrtrv&DocNm=CVM_1-480710-0&DocType=Customer%20View%20Model&DocLang=English&DocFormat=2d_dxf.zip&PartCntxt=1-480710-0 |
| ENG_CVM_CVM_1-480710-0_CC1.3d_igs.zip | https://www.te.com/commerce/DocumentDelivery/DDEController?Action=srchrtrv&DocNm=CVM_1-480710-0&DocType=Customer%20View%20Model&DocLang=English&DocFormat=3d_igs.zip&PartCntxt=1-480710-0 |
| ENG_CVM_CVM_1-480710-0_CC1.3d_stp.zip | https://www.te.com/commerce/DocumentDelivery/DDEController?Action=srchrtrv&DocNm=CVM_1-480710-0&DocType=Customer%20View%20Model&DocLang=English&DocFormat=3d_stp.zip&PartCntxt=1-480710-0 |
| ENG_DS_Applicators-Partner-Vendors_2608.pdf | https://www.te.com/commerce/DocumentDelivery/DDEController?Action=srchrtrv&DocNm=Applicators-Partner-Vendors&DocType=Data%20Sheet&DocLang=English&DocFormat=pdf&PartCntxt=1-480710-0 |
| ENG_SS_108-1031_P.pdf | https://www.te.com/commerce/DocumentDelivery/DDEController?Action=srchrtrv&DocNm=108-1031&DocType=Specification%20Or%20Standard&DocLang=English&DocFormat=pdf&PartCntxt=1-480710-0 |
| ENG_SS_110-213_A2.pdf | https://www.te.com/commerce/DocumentDelivery/DDEController?Action=srchrtrv&DocNm=110-213&DocType=Specification%20Or%20Standard&DocLang=English&DocFormat=pdf&PartCntxt=1-480710-0 |
| ENG_SS_114-1010_V3.pdf | https://www.te.com/commerce/DocumentDelivery/DDEController?Action=srchrtrv&DocNm=114-1010&DocType=Specification%20Or%20Standard&DocLang=English&DocFormat=pdf&PartCntxt=1-480710-0 |
| ENG_SS_408-7300_E.pdf | https://www.te.com/commerce/DocumentDelivery/DDEController?Action=srchrtrv&DocNm=408-7300&DocType=Specification%20Or%20Standard&DocLang=English&DocFormat=pdf&PartCntxt=1-480710-0 |
| ENG_SS_408-7714_H.pdf | https://www.te.com/commerce/DocumentDelivery/DDEController?Action=srchrtrv&DocNm=408-7714&DocType=Specification%20Or%20Standard&DocLang=English&DocFormat=pdf&PartCntxt=1-480710-0 |
| Fastening Type | Latch Lock |
| Features | - |
| Glow Wire Rating | Standard Part - Not Glow Wire |
| Housing Color | Natural |
| Housing Material | Nylon |
| HTSUS编码 | 8538.90.6000 |
| Insulation Material | Polyamide (PA), Nylon |
| JPHTS | 853890000 |
| Multiple Contact Types | Without |
| MXHTS | 8538900100 |
| Number of Signal Positions | 0 |
| Operating Voltage (VAC) | 600 |
| Packaging Method | Package |
| Packaging Quantity | 1 |
| Primary Product Color | Natural |
| Product Features & Characteristics | Select All |
| Product Series | Universal MATE-N-LOK |
| REACH状态 | REACH not applicable |
| RoHS状态 | RoHS Compliant |
| Row Spacing | 0.250" (6.35mm) |
| Row-to-Row Spacing | 6.35 mm [ .25 in ] |
| Sealable | No |
| Standard Pack Qty | 850 |
| TARIC | 8547200090 |
| Termination Method to Wire & Cable | Crimp |
| TE内部描述 | 15P UMNL PLUG HSG NATL |
| TE内部编号 | 1-480710-0 |
| UL Flammability Rating | UL 94V-2 |
| UL Rating | Recognized |
| UL 等级 | 获得认可 |
| USHTS | 8538906000 |
| 中心线（间距） | .25 in |
| 交期 | 98 Days |
| 产品名称 | 1-480710-0 (TE Connectivity) |
| 产品描述 | Rectangular Power Connectors, Housing, Plug, Wire-to-Wire / Wire-to-Board, 15 Position, 6.35 mm [.25 in] Centerline, Universal MATE-N-LOK |
| 产品状态 | Id：0；Status：Active |
| 产品间距 | 6.35mm |
| 产地 | 中国/CHN |
| 信号位置数量 | 0 |
| 公端/母端 | 插座 |
| 制造商交期（周） | 15 |
| 包装方式 | - |
| 单位重量（kg） | 0.0084 |
| 参考单价（USD） | 0.88 |
| 可密封性 | 否 |
| 可用库存 | 1926 |
| 品名 | 塑壳 |
| 品牌归属地 | 国际 |
| 基本分类 | 连接器, 工控电气 |
| 壳体内的端子定位力 | 不带 |
| 壳体颜色 | 土黄色 |
| 外壳材料 | 尼龙 |
| 多端子类型 | 不带 |
| 子品牌 | AMP |
| 官方产品图片1 | https://www.te.com/content/dam/te-com/catalog/part/014/807/100/1-480710-0-t1.jpg/jcr:content/renditions/product-details.png |
| 封装数量 | 1 |
| 工作温度范围 | -67 – 221 °F |
| 工作电压 | 600 VAC |
| 年份批次 | 202608 |
| 引脚配置类型 | 3x5 |
| 数据手册 | https://www.te.com/commerce/DocumentDelivery/DDEController?Action=srchrtrv&DocNm=408-7714&DocType=SS&DocLang=English |
| 替代型号 | 92T9-00044（JiDC(济德)）、9635HM-3*05-N2（SIWEB）、1-480710-1（TE） |
| 湿敏等级 | 1 (Unlimited) |
| 灼热丝额定值 | 标准件 - 非灼热丝 |
| 电源位置数量 | 0 |
| 电路应用 | 电源和信号 |
| 矩形电源连接器类型 | 护套 |
| 端子布局 | 矩阵 |
| 端接方法 | 压接 |
| 行数 | 3 |
| 贸泽编号 | 571-14807100 |
| 连接器变种 | 不带端子 |
| 连接器和壳体类型 | 插头 |
| 连接器和端子端接到 | 电线和电缆 |
| 连接器系统 | 线到板 |
| 连接器高度 | 27.43 mm |
| 针位数 | 15 |
| 锁定系统 | 锁定 |
| 阻燃等级 | UL94 V-2 |
| 零件编号 | 1-480710-0 |
| 安装风格 | Free Hanging (In-Line) |
| 包装 | Bulk |
| 额定电压 | 600 VAC |
| 系列 | Universal MATE-N-LOK |
| 端接方式 | Crimp |
Related product information
Similar products for discovery (not a compatibility or replacement claim)
TE Connectivity 5-965906-1 Connector TerminalTE Connectivity 936207-1 Connector HousingTE Connectivity 3-1534127-1 Connector HousingTE Connectivity 2822357-1 Connector SealTE Connectivity 2822354-1 Connector SealTE Connectivity 963142-3 Connector SealTE Connectivity 1564411-7 Connector AccessoryTE Connectivity 1703278-2 Connector Terminal
Verified inquiry information
- Packaging
- -
- Minimum order quantity
- 1
Manufacturer and authorized source records
Product information
TE Connectivity 1-480710-0 Electrical Connector
1-480710-0 is a TE Connectivity Standard Rectangular Connectors. Review the verified specifications, packaging, compliance and availability information before ordering.
Part number
1-480710-0
Brand
TE Connectivity
Category
Standard Rectangular Connectors
Series
Universal MATE-N-LOK
Technical specifications
| Pitch | 6.35mm |
|---|---|
| Packaging | - |
| Brand region | International |
| Termination method | Crimp |
| Series | Universal MATE-N-LOK |
| Number of positions | 15 |
| Operating temperature | -67 – 221 °F |
| Standard Pack Qty | 850 |
| Connector Type | Plug |
| Contact Type | Male or Female |
| Number of Positions | 15 |
| Number of Rows | 3 |
| Row Spacing | 0.250" (6.35mm) |
| Mounting Type | Free Hanging (In-Line) |
| Contact Termination | Crimp |
| Fastening Type | Latch Lock |
| Color | Natural |
| Features | - |
| Insulation Material | Polyamide (PA), Nylon |
| Operating Temperature | -55°C ~ 105°C |
| Unit weight (kg) | 0.0084 |
| Connector Product Type | Housing |
| Connector & Housing Type | Plug |
| Connector System | Wire-to-Board | Wire-to-Wire |
| Contact Retention Within Housing | Without |
| U L Flammability Rating | UL 94V-2 |
| Product Features & Characteristics | Select All |
| Sealable | No |
| Connector & Contact Terminates To | Wire & Cable |
| Number Of Positions | 15 |
| Number Of Rows | 3 |
| Number Of Signal Positions | 0 |
| Operating Voltage ( V A C) | 600 |
| Primary Product Color | Natural |
| Contact Layout | Matrix |
| Multiple Contact Types | Without |
| Contact Type | Socket |
| Termination Method To Wire & Cable | Crimp |
| Connector Mounting Type | Free-Hanging (In-Line) |
| Centerline ( Pitch) | 6.35 mm [ .25 in ] |
Ordering and packaging
| Minimum order quantity | 1 |
|---|---|
| Order multiple | 1 |
| Factory stock | 0 |
Compliance information
| RoHS status | RoHS Compliant |
|---|---|
| REACH status | REACH not applicable |
| Moisture sensitivity level | 1 (Unlimited) |
| ECCN | EAR99 |
| CNHTS | 8547200000 |
| TARIC | 8547200090 |
| CAHTS | 8538903900 |
| USHTS | 8538906000 |
| JPHTS | 853890000 |
| MXHTS | 8538900100 |
| BRHTS | 85389090 |
| Country of Origin | China |
| Assembly Country of Origin | Not available |
| Country of Diffusion | Not available |
Specifications are provided for selection reference. Confirm the complete part number, packaging and latest manufacturer documentation before ordering.
