Product information
Molex 50079-8000 Connector Terminal
50079-8000 is a Molex Crimp Terminals. Review the verified specifications, packaging, compliance and availability information before ordering.
Part number
50079-8000
Brand
Molex
Category
Crimp Terminals
Series
PicoBlade 50079
Applications
Connected Home, Telecommunications / Networking, Defense, Wire-to-Wire, Wire-to-Board
Technical specifications
| Product status | Active |
|---|---|
| Gender | Female |
| Brand region | International |
| Termination method | Crimp |
| Series | PicoBlade 50079 |
| Wire size (AWG) | 28 to 26 AWG |
| Contact plating | Tin |
| Plating thickness | 0.9μm |
| Primary applications | Connected Home,Telecommunications / Networking,Defense |
| Secondary applications | Wire-to-Wire Connectors, Wire-to-Board Connectors, Micro Connector Products |
| Packaging | Reel |
| Standard Pack Qty | 25000 |
| Unit weight (kg) | 1.01e-05 |
| Durability Mating Cycles Max | 30 |
| Interface gender | Female |
| Material Metal | Phosphor Bronze |
| Material Plating Mating | Tin |
| Material Plating Termination | Tin |
| Net weight | 27.100/mg |
| Plating Min Mating | 0.889µm |
| Plating Min Termination | 0.889µm |
| Termination Interface Style | Crimp or Compression |
| Wire Insulation Diameter | 0.50-1.04mm |
| Wire Size Awg | 26、28 |
| Wire Size Mm | N/A |
Ordering and packaging
| Minimum order quantity | 25000 |
|---|---|
| Order multiple | 25000 |
| Factory stock | 0 |
| Suggested alternative | 538-50079-8100 |
| Packaging type | Reel |
Compliance information
| CNHTS | 8536901100 |
|---|---|
| TARIC | 8536699099 |
| CAHTS | 8536900020 |
| USHTS | 8536904000 |
| JPHTS | 8536900002 |
| KRHTS | 8536909010 |
| MXHTS | 85369099 |
| BRHTS | 85369090 |
| ECCN | EAR99 |
| Country of Origin | Malaysia |
| Assembly Country of Origin | Not available |
| Country of Diffusion | Not available |
| RoHS status | RoHS Compliant |
| GADSL/IMDS | Compliant with Exemption 44 |
| China RoHS | Green Image per SJ/T 11365-2006 |
| EU ELV | Compliant per 2000/53/EC |
| Low-Halogen Status | Low-Halogen per IEC 61249-2-21 |
| Prop65 | Compliant per California Proposition 65 |
| REACH SVHC | Not Contained per D(2025)7771-DC (04 Feb 2026) |
| EU RoHS | Compliant per EU 2015/863 |
Mating and related products
| Use-with series | 51021 - PicoBlade Single Row Receptacle Housings |
|---|
Additional information
| Country of origin | HK,JP,MY,US |
|---|
Specifications are provided for selection reference. Confirm the complete part number, packaging and latest manufacturer documentation before ordering.
