Related product information
Brand：Molex
Category：Crimp Terminals
Series：Pico-Clasp Wire-to-Board Connectors
Application：Connected Home
Application：Telecommunications / Networking
Application：Defense
Application：Signal Connections
Application：Wire-to-Board
Application：Wire-to-Wire
Similar products for discovery (not a compatibility or replacement claim)
Verified inquiry information
- Packaging
- Reel
- Minimum order quantity
- 25000
- Packaging type
- Reel
Manufacturer and authorized source records
Product information
Molex 501334-0000 Connector Terminal
501334-0000 is a Molex Crimp Terminals. Review the verified specifications, packaging, compliance and availability information before ordering.
Part number
501334-0000
Brand
Molex
Category
Crimp Terminals
Series
Pico-Clasp Wire-to-Board Connectors
Applications
Connected Home, Telecommunications / Networking, Defense, Signal Connections, Wire-to-Board, Wire-to-Wire
Technical specifications
| Product status | Active |
|---|---|
| Gender | Female |
| Packaging | Reel |
| Brand region | International |
| Termination method | Crimp |
| Series | 501334、501334 |
| Wire size (mm²) | N/A |
| Wire size (AWG) | 32 to 28 AWG |
| Contact plating | Tin |
| Primary applications | Connected Home,Telecommunications / Networking,Defense |
| Secondary applications | Wire-to-Board Connectors, Micro Connector Products |
| Product family | Pico-Clasp |
| Product series | Pico-Clasp Wire-to-Board Connectors |
| Wire insulation diameter | 0.80mm max. |
| Applications | Signal, Wire-to-Board, Wire-to-Wire |
| Category | Crimp Terminals |
| Description | 1.00mm Pitch, Pico-Clasp Female Crimp Terminal, Tin Plating, 28-32 AWG, Reel |
| Weight | 17.000/mg |
| Metal material | Phosphor Bronze |
| Packaging | Reel |
| Standard Pack Qty | 25000 |
| Type | - |
| Pin or Socket | Socket |
| Contact Termination | Crimp |
| Wire Gauge | 28-32 AWG |
| Contact Finish | Tin |
| Contact Finish Thickness | 39.4µin (1.00µm) |
| Unit weight (kg) | 8.60000001e-06 |
| Durability Mating Cycles Max | 30 |
| Interface gender | Female |
| Material Metal | Phosphor Bronze |
| Material Plating Mating | Tin |
| Material Plating Termination | Tin |
| Net weight | 17.000/mg |
| Packaging Alternative Part | {'productNumber': '5013340100', 'packagingType': 'Bag'} |
| Termination Interface Style | Crimp or Compression |
Ordering and packaging
| Minimum order quantity | 25000 |
|---|---|
| Order multiple | 25000 |
| Factory stock | 0 |
| Suggested alternative | 538-501334-0100 |
| Packaging type | Reel |
Compliance information
| RoHS status | ROHS3 Compliant |
|---|---|
| REACH status | REACH Unaffected |
| Moisture sensitivity level | 1 (Unlimited) |
| ECCN | EAR99 |
| CNHTS | 8536901100 |
| TARIC | 8536699099 |
| CAHTS | 8536900020 |
| USHTS | 8536904000 |
| JPHTS | 8536900002 |
| KRHTS | 8536909010 |
| MXHTS | 85369099 |
| BRHTS | 85369090 |
| Country of Origin | Malaysia |
| Assembly Country of Origin | Not available |
| Country of Diffusion | Not available |
| GADSL/IMDS | Compliant with Exemption 44 |
| China RoHS | Green Image per SJ/T 11365-2006 |
| EU ELV | Compliant per 2000/53/EC |
| Low-Halogen Status | Low-Halogen per IEC 61249-2-21 |
| Prop65 | Compliant per California Proposition 65 |
| REACH SVHC | Not Contained per D(2025)7771-DC (04 Feb 2026) |
| EU RoHS | Compliant per EU 2015/863 |
Mating and related products
| Use-with series | 501330 - Pico-Clasp Low-Halogen Single Row Receptacle Housings |
|---|
Additional information
| Country of origin | JP,MY,US |
|---|
Specifications are provided for selection reference. Confirm the complete part number, packaging and latest manufacturer documentation before ordering.
