Molex 50752-8200 Connector Terminal

50752-8200 is a Molex Crimp Terminals. Review the verified specifications, packaging, compliance and availability information before ordering.

¥ 0.06

Packaging
- Piece
- Carton
- Reel

Add to cart

Add to wishlist

Sales and Website Terms
Price, availability, and lead time are subject to order confirmation

Hong Kong standard delivery: 17:00 cutoff, 3 business days handling + 3 business days transit, Monday–Friday, free shipping. View shipping policy

产品技术规格

应用领域	Wire-to-Board
1	0.119
10000	0.071
100000	0.067
20	0.113
200000	0.065
3D CAD图纸	https://www.molex.com/content/dam/molex/molex-dot-com/products/automated/en-us/3dcadmodelspdf/507/50752/507528200.pdf
3D CAD模型	https://www.molex.com/content/dam/molex/molex-dot-com/products/automated/en-us/3dcadmodels/507/50752/507528200_stp.zip
50000	0.069
Assembly Country of Origin	Not available
batch	N
China RoHS	Green Image per SJ/T 11365-2006
CNHTS	8536901100
Country of Diffusion	Not available
Country of Origin	Korea, Republic of
Crimp Specification Pdf	https://www.molex.com/content/dam/molex/molex-dot-com/products/automated/en-us/crimpspecificationpdf/507/50752/507520000-CS-000.pdf
Durability Mating Cycles Max	30
ECCN	EAR99
EU ELV	Not Relevant
EU RoHS	Compliant per EU 2015/863
GADSL/IMDS	Compliant with Exemption 44
Low-Halogen Status	Low-Halogen per IEC 61249-2-21
Material Metal	Phosphor Bronze
Material Plating Mating	Matte Tin
Material Plating Termination	Matte Tin
Prop65	Compliant per California Proposition 65
REACH SVHC	Not Contained per D(2025)7771-DC (04 Feb 2026)
RoHS状态	RoHS Compliant
SAP型号	0507528200
Standard Pack Qty	10000
TARIC	8536699099
Termination Interface Style	Crimp or Compression
USHTS	8536904000
Wire Insulation Diameter	1.50-1.80mm
Wire Size Awg	20、22
Wire Size Mm	N/A
一级应用	Appliances
二级应用	Wire-to-Board Connectors, Micro Connector Products
交期	70 Days
产品名称	50752-8200 (MOLEX)
产品描述	2.50mm Pitch, Mini-Lock Female Crimp Terminal, Matte Tin Plating, 20-22 AWG, Reel
产品状态	Active
产品系列	Mini-Lock
产品链接	https://www.mouser.hk/en/ProductDetail/Molex/50752-8200?qs=qSfuJ%252Bfl%2Fd537vA0cNw4ow%3D%3D
产地	韩国/KOR
公端/母端	母端
包装方式	卷
包装类型	Reel
包装规范	https://www.molex.com/content/dam/molex/molex-dot-com/products/automated/en-us/packagingspecificationpdf/507/50752/507529200-SPK-200.pdf
单位重量（kg）	6.7e-05
原产国	JP,KR
品名	盘装端子
品牌归属地	国际
基本分类	连接器
导线绝缘直径	1.50-1.80mm
接口性别	Female
替代型号	921-060-1001（JiDC(济德)）
最后更新日期	2026-09-28
最多次数耐用性(插拔次数)	30
最大电压	250V AC (RMS)/DC
端接方法	压接
线径-mm²	N/A
线规-AWG	20 AWG,22 AWG
终端电镀材料	Matte Tin
触头镀层	锡
说明	2.50mm Pitch, Mini-Lock Female Crimp Terminal, Matte Tin Plating, 20-22 AWG, Reel
贸泽编号	538-50752-8200
配套系列	51163 - Mini-Lock Single Row Receptacle Housings
金属材料	Phosphor Bronze
销售图纸	https://www.molex.com/content/dam/molex/molex-dot-com/products/automated/en-us/salesdrawingpdf/507/50752/507528200_sd.pdf
销售状态	Standard Product
首次发布日期	2018-09-18
高清产品图片	https://www.molex.com/content/dam/molex/molex-dot-com/products/manual/en-us/images/507/50752/0507528200_hires.jpg
包装	Reel
额定电流	3.5A
系列	50752、50752
重量	66.920/mg

Brand：Molex Category：Crimp Terminals Series：Mini-Lock Wire-to-Board Connector System Application：Appliances Application：Signal Connections Application：Wire-to-Board
