产品技术规格
| 1 | 159.669 |
|---|---|
| 1000 | 101.059 |
| 1734-1185-ND | Bulk |
| 20 | 152.066 |
| 200 | 103.946 |
| 2000 | 98.171 |
| 3D_CVM_CVM_HDP26-24-31PE_D.pdf | https://www.te.com/commerce/DocumentDelivery/DDEController?Action=srchrtrv&DocNm=CVM_HDP26-24-31PE&DocType=Customer%20View%20Model&DocLang=3D&DocFormat=pdf&PartCntxt=HDP26-24-31PE |
| 4000 | 96.247 |
| Assembly Country of Origin | Not available |
| batch | N |
| Blank Cavity Position | 0 |
| BRHTS | 85367000 |
| Cable Exit Angle (°) | 180 |
| CAHTS | 8536700000 |
| Circuit Application | Power |
| CNHTS | 8538900000 |
| Compatible Insulation Diameter Range | 1.4 – 3.8 mm [ .055 – .15 in ] |
| Connector & Contact Terminates To | Wire & Cable |
| Connector Height | 38.6 mm [ 1.52 in ] |
| Connector & Housing Type | Housing for Male Terminals |
| Connector Mounting Type | Panel Mount |
| Connector Position Assurance Capable | No |
| Connector Seal Code | E Seal |
| Connector Shape | Circular |
| Connector System | Wire-to-Panel |
| Connector Type | Plug Housing |
| Contact Current Rating (Max) (A) | 13 |
| Country of Diffusion | Not available |
| Country of Origin | United States |
| Customer Drawing | https://www.te.com/commerce/DocumentDelivery/DDEController?Action=srchrtrv&DocNm=HDP26-24-XXP/SX&DocType=Customer%20Drawing&DocLang=English&DocFormat=pdf&PartCntxt=HDP26-24-31PE |
| DigiKey编号 | 1734-1185-ND |
| ECCN | EAR99 |
| ENG_AAD_UL_CERT_E28476_20090713_C1_B.pdf | https://www.te.com/commerce/DocumentDelivery/DDEController?Action=srchrtrv&DocNm=UL_CERT_E28476_20090713_C1&DocType=Agency%20Approval%20Document&DocLang=English&DocFormat=pdf&PartCntxt=HDP26-24-31PE |
| ENG_CS_8-1773982-0_A.pdf | https://www.te.com/commerce/DocumentDelivery/DDEController?Action=srchrtrv&DocNm=8-1773982-0&DocType=Catalog%20Section&DocLang=English&DocFormat=pdf&PartCntxt=HDP26-24-31PE |
| ENG_CVM_CVM_HDP26-24-31PE_D.2d_dxf.zip | https://www.te.com/commerce/DocumentDelivery/DDEController?Action=srchrtrv&DocNm=CVM_HDP26-24-31PE&DocType=Customer%20View%20Model&DocLang=English&DocFormat=2d_dxf.zip&PartCntxt=HDP26-24-31PE |
| ENG_CVM_CVM_HDP26-24-31PE_D.3d_igs.zip | https://www.te.com/commerce/DocumentDelivery/DDEController?Action=srchrtrv&DocNm=CVM_HDP26-24-31PE&DocType=Customer%20View%20Model&DocLang=English&DocFormat=3d_igs.zip&PartCntxt=HDP26-24-31PE |
| ENG_CVM_CVM_HDP26-24-31PE_D.3d_stp.zip | https://www.te.com/commerce/DocumentDelivery/DDEController?Action=srchrtrv&DocNm=CVM_HDP26-24-31PE&DocType=Customer%20View%20Model&DocLang=English&DocFormat=3d_stp.zip&PartCntxt=HDP26-24-31PE |
| ENG_DS_1-1773950-7_A.pdf | https://www.te.com/commerce/DocumentDelivery/DDEController?Action=srchrtrv&DocNm=1-1773950-7&DocType=Data%20Sheet&DocLang=English&DocFormat=pdf&PartCntxt=HDP26-24-31PE |
| ENG_SS_0425-014-2400_H.pdf | https://www.te.com/commerce/DocumentDelivery/DDEController?Action=srchrtrv&DocNm=0425-014-2400&DocType=Specification%20Or%20Standard&DocLang=English&DocFormat=pdf&PartCntxt=HDP26-24-31PE |
| ENG_SS_108-151015_C.pdf | https://www.te.com/commerce/DocumentDelivery/DDEController?Action=srchrtrv&DocNm=108-151015&DocType=Specification%20Or%20Standard&DocLang=English&DocFormat=pdf&PartCntxt=HDP26-24-31PE |
| ENG_SS_114-151015_C6.pdf | https://www.te.com/commerce/DocumentDelivery/DDEController?Action=srchrtrv&DocNm=114-151015&DocType=Specification%20Or%20Standard&DocLang=English&DocFormat=pdf&PartCntxt=HDP26-24-31PE |
| ENG_SS_501-151033_B.pdf | https://www.te.com/commerce/DocumentDelivery/DDEController?Action=srchrtrv&DocNm=501-151033&DocType=Specification%20Or%20Standard&DocLang=English&DocFormat=pdf&PartCntxt=HDP26-24-31PE |
| ENG_SS_502-151015_A.pdf | https://www.te.com/commerce/DocumentDelivery/DDEController?Action=srchrtrv&DocNm=502-151015&DocType=Specification%20Or%20Standard&DocLang=English&DocFormat=pdf&PartCntxt=HDP26-24-31PE |
| Fastening Type | Bayonet Lock |
| Features | Coupling Nut |
| Housing Color | Black |
| Housing Material | PA 66 GF |
| HTSUS编码 | 8538.90.6000 |
| 防护等级 | IP68 - Dust Tight, Waterproof |
| 防护等级 | IP67 |
| JPHTS | 853890000 |
| Material Flammability Rating | UL94 V-1 |
| Mating Alignment | With |
| Mating Alignment Type | Polarizing Slot |
| Mating Pin Diameter | 1.6 mm [ .063 in ] |
| Mixed & Hybrid Connector | No |
| MXHTS | 85367001 |
| Nominal Voltage Architecture (V) | 12 | 24 | 48 |
| 工作温度（Max） | 125 °C [ 257 °F ] |
| 工作温度 | -55 – 125 °C [ -67 – 257 °F ] |
| Operating Voltage (VAC) | 250 |
| Operating Voltage (VDC) | 250 |
| Orientation | Keyed |
| Packaging Method | Tray |
| Packaging Quantity | 40 |
| Primary Locking Feature | Contact Retainer |
| Primary Product Color | Black |
| Product Features & Characteristics | Select All |
| Product Length | 49.5 mm [ 1.95 in ] |
| Product Width | 49.5 mm [ 1.95 in ] |
| REACH-SVHC | Octamethylcyclotetrasiloxane [D4] (556-67-2)、Decamethylcyclopentasiloxane [D5] (541-02-6)、Dodecamethylcyclohexasiloxane [D6] (540-97-6) |
| REACH状态 | REACH Unaffected |
| Sealable | Yes |
| Serviceable | Yes |
| Shell Finish | - |
| Shell Material | Polyamide (PA66), Nylon 6/6, Glass Filled |
| Shell Size - Insert | 24-31 |
| Shell Size, MIL | - |
| Shielding | Unshielded |
| Standard Pack Qty | 40 |
| Strain Relief | Without |
| TARIC | 8536700099 |
| Terminal Position Assurance | No |
| TE内部描述 | PLG, 31P, BLK, E, 16, P |
| TE内部编号 | HDP26-24-31PE |
| Type | For Male Pins |
| UL Flammability Rating | UL 94V-0 |
| USHTS | 8538908180 |
| 主体颜色 | 黑色 |
| 主要锁定特性 | 触点固定器 |
| 交期 | 91 Days |
| 产品别名 | $$HDP26-24-31PE |
| 产品名称 | HDP26-24-31PE (TE Connectivity) |
| 产品宽度 | 1.95 in |
| 产品描述 | Housing for Male Terminals, Wire-to-Wire, 31 Position, Sealable, Black, Wire & Cable, Power & Signal, Cable Mount (Free-Hanging), Hybrid |
| 产品状态 | Id：0；Status：Active |
| 产品长度 | 1.521 in |
| 产地 | 美国/USA |
| 公端/母端 | 公端 |
| 制造商交期（周） | 13 |
| 包装方式 | 盒 |
| 单位重量（kg） | 0.0453 |
| 参考单价（USD） | 19.85 |
| 可密封 | 是 |
| 可用库存 | 586 |
| 可维修 | 是 |
| 品名 | 塑壳 |
| 品牌归属地 | 国际 |
| 基本分类 | 连接器 |
| 外壳材料 | PA GF |
| 官方产品图片1 | https://www.te.com/catalog/common/images/PartImages/prhdp26-24-31pe.jpg |
| 工作温度（Max） | 257 °F |
| 工作温度范围 | -67 – 257 °F |
| 工作电压 | 250 VDC |
| 应力消除 | 按附件添加 |
| 接合对准 | 带有 |
| 接合对准类型 | 引导槽 |
| 插片宽度 | .063 in |
| 数据手册 | https://www.te.com/commerce/DocumentDelivery/DDEController?Action=srchrtrv&DocNm=1-1773950-7&DocType=Data%20Sheet&DocLang=English&DocFormat=pdf&PartCntxt=HDP26-24-31PE |
| 方向 | 180° |
| 标称电压架构 | 12 V |
| 混合型连接器 | 否 |
| 湿敏等级 | Not Applicable |
| 电路应用 | 电源和信号 |
| 空白孔位 | 0 |
| 端子位置保证 | 否 |
| 端子大小 | 尺寸 16 |
| 端子额定电流(Max) | 13 A |
| 能够保证连接器位置 | 否 |
| 贸泽编号 | 571-HDP26-24-31PE |
| 连接器和端子端接到 | 电线和电缆 |
| 连接器密封件代码 | E 密封件 |
| 连接器形状 | 圆形 |
| 连接器系统 | 线到线 |
| 连接器高度 | 1.95 in |
| 适用的绝缘层直径范围 | .053 – .106 in |
| 针位数 | 31 |
| 防护等级 | IP67 |
| 阻燃等级 | UL-94 |
| 包装 | Bulk |
| 芯数 | 31 |
| 系列 | HDP20 |
Related product information
Similar products for discovery (not a compatibility or replacement claim)
TE Connectivity 5-965906-1 Connector TerminalTE Connectivity 936207-1 Connector HousingTE Connectivity 3-1534127-1 Connector HousingTE Connectivity 2822357-1 Connector SealTE Connectivity 2822354-1 Connector SealTE Connectivity 963142-3 Connector SealTE Connectivity 1564411-7 Connector AccessoryTE Connectivity 1703278-2 Connector Terminal
Verified inquiry information
- Packaging
- Bulk
- Minimum order quantity
- 1
Manufacturer and authorized source records
Product information
TE Connectivity HDP26-24-31PE Connector Housing
HDP26-24-31PE is a TE Connectivity Automotive Housings. Review the verified specifications, packaging, compliance and availability information before ordering.
Part number
HDP26-24-31PE
Brand
TE Connectivity
Category
Automotive Housings
Series
HD
Technical specifications
| Gender | Male |
|---|---|
| Brand region | International |
| Series | HD |
| Number of positions | 31 |
| Operating temperature | -67 – 257 °F |
| Packaging | Bulk |
Ordering and packaging
| Minimum order quantity | 1 |
|---|---|
| Order multiple | 1 |
| Factory stock | 0 |
Compliance information
| RoHS status | ROHS3 Compliant |
|---|---|
| REACH status | REACH Unaffected |
| Moisture sensitivity level | Not Applicable |
| ECCN | EAR99 |
| REACH-SVHC | Octamethylcyclotetrasiloxane [D4] (556-67-2)、Decamethylcyclopentasiloxane [D5] (541-02-6)、Dodecamethylcyclohexasiloxane [D6] (540-97-6) |
| CNHTS | 8538900000 |
| TARIC | 8536700099 |
| CAHTS | 8536700000 |
| USHTS | 8538908180 |
| JPHTS | 853890000 |
| MXHTS | 85367001 |
| BRHTS | 85367000 |
| Country of Origin | United States |
| Assembly Country of Origin | Not available |
| Country of Diffusion | Not available |
Specifications are provided for selection reference. Confirm the complete part number, packaging and latest manufacturer documentation before ordering.
