Product information
Molex 34967-4001 Connector Housing
34967-4001 is a Molex Connector Housings. Review the verified specifications, packaging, compliance and availability information before ordering.
Part number
34967-4001
Brand
Molex
Category
Connector Housings
Series
Mini50 Connection Systems
Applications
Automotive, Power Connections, Sealed Connections, Wire-to-Board
Technical specifications
| Product status | Active |
|---|---|
| Pitch | 1.80mm |
| Gender | Female |
| Packaging | Bag |
| Brand region | International |
| Number of rows | 1 |
| Series | 34967、34967 |
| Number of positions | 4 |
| Primary applications | Automotive |
| Secondary applications | Power Connectors, Mini50 Connection Systems, Wire-to-Board Connectors |
| Product family | Mini50 Sealed |
| Product series | Mini50 Connection Systems |
| Operating temperature | -40° to +105°C, -40° to +125°C |
| Applications | Automotive, Power, Sealed, Wire-to-Board |
| Mating polarization | Yes |
| Resin material | SPS/Nylon |
| Resin color | Black |
| Related series | Molex does not manufacture the mating header interface. To provide you with maximum design flexibility, we include the interface specification drawing with the part drawing, and a 3D model is available at the following URL so that you may design the interface into your device as you require: COMING SOON |
| Glow-wire capable | No |
| Category | Connector Housings |
| Description | Mini50 Sealed Receptacle, Single Row, with CPA, 4 Circuits, Polarization Option A, Black、-40°C to +105°C operating temperature for tin terminals; -40°C to +125°C operating temperature for silver terminals |
| Weight | 2.765/g |
| Panel mount | No |
| Standard Pack Qty | 2400 |
| Unit weight (kg) | 0.003453 |
| Maximum circuits | 4 |
| Color | Black |
| Interface gender | Receptacle |
| Glow-wire capable | No |
| Mating keying | Yes |
| Mating lock | Yes |
| Net weight | 3.300/g |
| Panel mount | No |
| Mating pitch | 1.80mm |
| Pitch Termination Interface | 1.80mm |
| Polarization | A |
Ordering and packaging
| Minimum order quantity | 1 |
|---|---|
| Order multiple | 1 |
| Factory stock | 0 |
| Packaging type | Bag |
Compliance information
| REACH-SVHC | Dodecamethylcyclohexasiloxane [D6] (540-97-6)、Decamethylcyclopentasiloxane [D5] (541-02-6)、Octamethylcyclotetrasiloxane [D4] (556-67-2) |
|---|---|
| CNHTS | 8538900000 |
| TARIC | 8547200090 |
| CAHTS | 8538909090 |
| USHTS | 8538906000 |
| BRHTS | 85389090 |
| ECCN | EAR99 |
| Country of Origin | China |
| Assembly Country of Origin | Not available |
| Country of Diffusion | Not available |
| RoHS status | RoHS Compliant |
| GADSL/IMDS | Compliant |
| China RoHS | Green Image per SJ/T 11365-2006 |
| EU ELV | Compliant per 2000/53/EC |
| Low-Halogen Status | Low-Halogen per IEC 61249-2-21 |
| Prop65 | Compliant per California Proposition 65 |
| REACH SVHC | Contains Dodecamethylcyclohexasiloxane; Decamethylcyclopentasiloxane; Octamethylcyclotetrasiloxane per D(2025)7771-DC (04 Feb 2026) |
| EU RoHS | Compliant per EU 2015/863 |
Mating and related products
| Use-with series | 34905 - CTX50 Sealed Receptacle Terminals |
|---|
Additional information
| Country of origin | CN |
|---|
Specifications are provided for selection reference. Confirm the complete part number, packaging and latest manufacturer documentation before ordering.
