39-00-0077

Molex 39-00-0077 Connector Terminal

39-00-0077 is a Molex Crimp Terminals. Review the verified specifications, packaging, compliance and availability information before ordering.

¥ 0.08 ¥ 0.08
Contact for quotation
  • Brand
  • Packaging
Add to cart
Add to wishlist
Sales and Website Terms
Price, availability, and lead time are subject to order confirmation
Contact Us
Hong Kong standard delivery: 17:00 cutoff, 3 business days handling + 3 business days transit, Monday–Friday, free shipping. View shipping policy

产品技术规格

应用领域 Wire-to-Board、Wire-to-Wire
1 0.178
20 0.17
20000 0.104
4000 0.107
40000 0.101
4701-3900-0077-ND Retail Package
80000 0.099
Assembly Country of Origin Not available
batch N
BRHTS 85369090
CAHTS 8536900020
China RoHS Green Image per SJ/T 11365-2006
CNHTS 8536901100
Contact Gender Socket
Contacts pitch 4.2mm
Country of Diffusion Not available
Country of Origin United States
DigiKey编号 4701-3900-0077-ND
Durability Mating Cycles Max 30
ECCN EAR99
Electrical mounting crimped
EU ELV Compliant per 2000/53/EC
EU RoHS Compliant per EU 2015/863
For Use With Molex Mini-Fit Jr. 5557, Mini-Fit TPA 30067 & Mini-Fit BMI 42474 Series Rcpt Housing Connectors
For Use With/Related Products General Purpose
GADSL/IMDS Compliant with Exemption 44
JPHTS 853690000
Kind of package reel
KRHTS 8536909010
Low-Halogen Status Low-Halogen per IEC 61249-2-21
Material Metal Brass
Material Plating Mating Tin
Material Plating Termination Tin
MXHTS 8536902800
Number of pieces on reel 4000pcs.
Packaging Alternative Part {'productNumber': '0039000078', 'packagingType': 'Bag'}
Packaging Design Drawing https://www.molex.com/content/dam/molex/molex-dot-com/products/automated/en-us/packagingdesigndrawing/555/5556/55560001-PK-000.pdf
Plating Min Mating 0.889µm
Plating Min Termination 0.889µm
Product Range Mini-Fit Jr. 5556 Series
Prop65 Compliant per California Proposition 65
REACH SVHC Not Contained per D(2025)7771-DC (04 Feb 2026)
REACH状态 REACH Unknown
SAP型号 0039000077
Standard Pack Qty 4000
TARIC 8536901000
Termination Interface Style Crimp or Compression
Tool Type Brake Tool
USHTS 8536904000
Wire Insulation Diameter 1.80-3.10mm
Wire Size Awg 16、22+18、20+20、22+20
Wire Size AWG Min 22AWG
Wire Size Mm N/A
一级应用 Appliances
二级应用 Wire-to-Board Connectors, Power Connectors, Wire-to-Wire Connectors, FiT Family Power Connectors, Mini-Fit Family Power Connectors
交期 73 Days
产品名称 39-00-0077 (MOLEX)
产品描述 Mini-Fit Female Crimp Terminal, Tin (Sn) over Copper (Cu) Plated Brass, 16, 18+22, 20+20, 20+22 AWG, Reel
产品系列 Mini-Fit
产地 美国/USA
公端/母端 母端
净重 135.300/mg
制造商交期（周） 0
包装方式 卷
包装类型 Reel
单位重量（kg） 0.0001353
原产国 BR,HK,IT,JP,US
参考单价（USD） 35.38
可用库存 9
品名 盘装端子
品牌归属地 国际
基本分类 连接器
导线绝缘直径 1.80-3.10mm
接口性别 Female
数据手册 https://d3d71ba2asa5oz.cloudfront.net/12015069/images/3900-0077p100923.jpg
替代包装型号 39-00-0077 (Cut Strip)、39-00-0077 (Mouser Reel)
替代型号 922-114-1015（JiDC(济德)）、9357TF-BSN-L（SIWEB）
最后更新日期 2026-10-14
最多次数耐用性(插拔次数) 30
最大电压 600V
端接方法 压接
端接最薄镀层 0.889µm
线径-mm² N/A
线规-AWG 22 to 16 AWG
终端电镀材料 Tin
触头镀层 锡
说明 Mini-Fit Female Crimp Terminal, Tin (Sn) over Copper (Cu) Plated Brass, 16, 18+22, 20+20, 20+22 AWG, Reel
贸泽编号 538-39-00-0077
配套系列 5557 - Mini-Fit Jr. Receptacle Housings、44516 - Mini-Fit BMI Dual Row Receptacle Housings、42474 - Mini-Fit BMI Dual Row Receptacle Housings、43760 - Mini-Fit BMI Dual Row Receptacle Housings、46992 - Mini-Fit Jr. Dual Row Receptacle Housings
金属材料 Brass
销售图纸 https://www.molex.com/content/dam/molex/molex-dot-com/products/automated/en-us/salesdrawingpdf/555/5556/039000077_sd.pdf
销售状态 Standard Product
镀层厚度 0.889μm
首次发布日期 2007-05-16
高清产品图片 https://www.molex.com/content/dam/molex/molex-dot-com/products/manual/en-us/images/555/5556/0039000077_hires.jpg
接触件材质 Brass
包装 Reel
额定电流 9A
系列 -
重量 135.300/mg
Brand：Molex Category：Crimp Terminals Series：Mini-Fit Family Power Connectors Application：Appliances Application：Power Connections Application：Wire-to-Board Application：Wire-to-Wire
