Product information
Molex 43645-0300 Connector Housing
43645-0300 is a Molex Connector Housings. Review the verified specifications, packaging, compliance and availability information before ordering.
Part number
43645-0300
Brand
Molex
Category
Connector Housings
Series
Micro-Fit Connector System
Applications
Agricultural Machinery, Appliances, Power Connections, Wire-to-Board, Wire-to-Wire, Board-to-Board
Technical specifications
| Product status | Active |
|---|---|
| Pitch | 3.00mm |
| Gender | Female |
| Packaging | Bag |
| Brand region | International |
| Number of rows | 1 |
| Series | 43645、43645 |
| Number of positions | 3 |
| Primary applications | Agricultural Machinery, Appliances |
| Secondary applications | Wire-to-Board Connectors, Power Connectors, Micro-Fit Connector System, Wire-to-Wire Connectors, Board-to-Board Connectors, FiT Family Power Connectors |
| Product family | Micro-Fit 3.0 |
| Product series | Micro-Fit Connector System |
| Operating temperature | -40° to +105°C |
| Applications | Power, Wire-to-Board, Wire-to-Wire |
| Mating polarization | None |
| Lead free | N/A |
| Resin material | Nylon |
| Resin color | Black |
| Related series | 43640, 200875, 43650, 214752, 214753 |
| Glow-wire capable | No |
| Category | Connector Housings |
| Description | Micro-Fit 3.0 Receptacle Housing, Single Row, 3 Circuits, UL 94V-0, Low-Halogen, Black |
| Weight | 0.456/g |
| Panel mount | No |
| Packaging | Bulk |
| Standard Pack Qty | 5000 |
| Unit weight (kg) | 0.00046 |
| Maximum circuits | 3 |
| Color | Black |
| Flammability | 94V-0 |
| Interface gender | Receptacle |
| Glow-wire capable | No |
| Mating keying | No |
| Mating lock | Yes |
| Net weight | 0.365/g |
| Panel mount | No |
Ordering and packaging
| Minimum order quantity | 1 |
|---|---|
| Order multiple | 1 |
| Factory stock | 0 |
| Packaging type | Bag |
Compliance information
| CNHTS | 8547200000 |
|---|---|
| TARIC | 8547200090 |
| CAHTS | 8536690020 |
| USHTS | 8538906000 |
| JPHTS | 853890000 |
| KRHTS | 8536691000 |
| MXHTS | 8538900100 |
| BRHTS | 85389090 |
| ECCN | EAR99 |
| Country of Origin | India |
| Assembly Country of Origin | Not available |
| Country of Diffusion | Not available |
| RoHS status | RoHS Compliant |
| GADSL/IMDS | Not Relevant |
| China RoHS | Green Image per SJ/T 11365-2006 |
| EU ELV | Compliant per 2000/53/EC |
| Low-Halogen Status | Low-Halogen per IEC 61249-2-21 |
| Prop65 | Compliant per California Proposition 65 |
| REACH SVHC | Not Contained per D(2025)7771-DC (04 Feb 2026) |
| EU RoHS | Compliant per EU 2015/863 |
| CSA | LR19980 |
| UL | E29179 |
Mating and related products
| Mating series | 43640 - Micro-Fit 3.0 Single Row Plug Housings、200875 - Micro-Fit TPA Single Row Plug Housings、43650 - Micro-Fit 3.0 Single Row Headers、214752 - Micro-Fit 3.0 Male-to-Micro-Fit 3.0 Male Off-the-Shelf (OTS) Cable Assemblies、214753 - Micro-Fit 3.0 Male-to-Pigtail Off-the-Shelf (OTS) Cable Assemblies |
|---|---|
| Use-with series | 43030 - Micro-Fit 3.0 Female Crimp Terminals、46235 - Micro-Fit Reduced Mating Force Female Crimp Terminals、214760 - Pre-Crimped Lead Micro-Fit 3.0 Female-to-Micro-Fit 3.0 Female、214761 - Pre-Crimped Lead Micro-Fit 3.0 Female-to-Pigtail |
Additional information
| Country of origin | CN,HK,IN,JP,MX,US |
|---|
Specifications are provided for selection reference. Confirm the complete part number, packaging and latest manufacturer documentation before ordering.
